Siemens 6DD1642-0BC0 SIMADYN D EA12 analog output module Original new

Siemens 6DD1642-0BC0 SIMADYN D EA12 analog output module Original new

Product Name:SIMADYN D EA12 analog output module

Brand Name:Siemens

Model Number:6DD1642-0BC0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6dd1642 0bc0 simadyn d ea12 analog output module original new-1

Overview
Get your discount today
Specifications
Description
Applications
Environment & Certification
Features & Benefits
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6DD1642-0BC0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Get your discount today

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6DD1642-0BC0, SIMADYN D EA12 analog output module, provides 8-channel precision analog signal output for industrial control systems
Output Channels	8 analog outputs, designed for multi-loop control and process automation applications
Output Range	±10 V voltage output, supports high-precision industrial signal regulation
Output Current	±10 mA maximum per channel, short-circuit protected for 120 seconds
Resolution	13-bit + sign resolution, equivalent to 1 mV signal precision
Interface Type	20-pin connector system with L-bus connection for SIMADYN D architecture integration
Calibration	Manual offset and gain adjustment via potentiometers per channel, supports field re-calibration
Dimension	20.14 mm × 233.4 mm × 220 mm, compact single-slot module design
Weight	Approx. 0.5 kg, lightweight structure for rack-mounted industrial systems

Description

The 6DD1642-0BC0 is a SIMADYN D EA12 analog output module designed for precise industrial signal control in automation and drive systems. It provides 8 high-resolution analog outputs, supporting stable voltage signal generation for process control and system regulation applications.

The 6DD1642-0BC0 features direct 20-pin interface connectivity and front-panel test sockets for easy commissioning and maintenance. Each output channel supports adjustable offset and gain calibration, allowing fine-tuning based on operating temperature and system requirements, ensuring high accuracy in dynamic industrial environments.

With robust electrical protection and short-circuit resistance, the 6DD1642-0BC0 ensures reliable operation in demanding control systems. It is widely used in power plants, heavy industry, and automated production lines requiring stable analog signal output performance.
