Product Name: SIMATIC TDC SB10 Binary Input/Output Interface Module
Brand Name: Siemens
Model Number: 6DD1681-0AE2
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
| Product Name | Siemens 6DD1681-0AE2 SIMATIC TDC SB10 Binary Input/Output Interface Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC TDC SB10 Binary Input/Output Interface Module |
| Part Number | 6DD1681-0AE2 |
| Weight | 0.24kg |
| Estimated shipping dimensions | 4.5x15.5x13cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| SIMATIC Connection | SC62 or SC66 cable |
| Digital Signals | 8 channels |
| Rated Signal Voltage | 24 V DC |
| Maximum Current per Channel | 30 mA |
| Supply Voltage | 24 V DC |
| Permissible Supply Voltage Range | 20.4 to 28.8 V DC |
| Short-term Overvoltage | 1.5 × rated voltage (t < 500 ms) |
| Current Consumption | Typical 20 mA |
| Maximum Current per Supply Line | 400 mA |
| Maximum Current Through Connector X3 | 1 A |
| Power Supply Connector Kit | SM11 (6DD1680-0BB0) |
| Maximum Conductor Cross-section | 2.5 mm² |
| Ambient Operating Temperature | Up to 60 °C |
| Diagnostic Function | Power status and short-circuit indication via LEDs |
| LED Indicators | Green (Power), Red (Power supply short-circuit fault) |
| Electrical Isolation | None (between SIMATIC side and plant side) |
| Mounting | DIN rail snap-on mounting |
| Connector X1 | Ribbon cable connector (8 digital signal pins + 2 supply pins) |
| Connector X2 | 2 × 8-pole terminal connector |
| Connector X3 | 1P / 1M power supply terminals |
| Test Socket | X5 double test socket (+24 V / 0 V) |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales |
|
Phone/Whatsapp |
|
Jim Pei |
Flexible Digital Signal Interface
Provides eight digital channels that can be configured for binary input or binary output applications, offering flexibility for a wide range of industrial control requirements.
Reliable System Diagnostics
Integrated LED indicators display power status and short-circuit conditions, allowing maintenance personnel to quickly identify faults and reduce system downtime.
Stable Industrial Signal Transmission
Designed for dependable 24 V DC digital communication, ensuring accurate signal exchange between field devices and SIMATIC TDC control systems.
Easy Installation and Wiring
Supports DIN rail mounting and standardized interface connections, simplifying installation, cable management, and maintenance within industrial control cabinets.
Seamless SIMATIC TDC Integration
Fully compatible with SIMATIC TDC rack systems and SC62/SC66 connection cables, enabling efficient system expansion and reliable communication with existing automation architectures.
Ideal for Industrial Control Applications
Well suited for power generation, industrial drive systems, process automation, turbine control, and other applications requiring dependable digital input and output interfacing.
Q1: What is the 6DD1681-0AE2 used for?
A: The 6DD1681-0AE2 is a binary input/output interface module used to exchange digital signals between field devices and SIMATIC TDC automation systems.
Q2: How many digital channels does the 6DD1681-0AE2 provide?
A: The 6DD1681-0AE2 provides eight digital signal channels that can be used for binary input or binary output applications, depending on the system configuration.
Q3: Does the 6DD1681-0AE2 include diagnostic functions?
A: Yes. The 6DD1681-0AE2 features integrated LED indicators that display power status and short-circuit faults, helping simplify diagnostics and maintenance.
Q4: Which SIMATIC systems are compatible with the 6DD1681-0AE2?
A: The 6DD1681-0AE2 is specifically designed for SIMATIC TDC automation systems and supports connection through SC62 or SC66 interface cables.
Q5: Is the 6DD1681-0AE2 easy to install?
A: Yes. The 6DD1681-0AE2 supports DIN rail mounting and standardized terminal connections, making installation and wiring straightforward in industrial control cabinets.
Q6: Which industrial applications are suitable for the 6DD1681-0AE2?
A: The 6DD1681-0AE2 is widely used in power generation, industrial drive systems, process automation, turbine control, and other industrial applications requiring reliable digital signal interfacing.
