Siemens 6DD1688-0AD0 SS4 communication module Ready For Ship

Siemens 6DD1688-0AD0 SS4 communication module Ready For Ship

Product Name:SS4 communication module

Brand Name:Siemens

Model Number:6DD1688-0AD0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6dd1688 0ad0 ss4 communication module ready for ship-1

Overview
Inquiry now
Specifications
Description
Applications
Environment and Certification
Features and Benefits
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6DD1688-0AD0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Inquiry now

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model:	6DD1688-0AD0 Siemens SS4 communication module designed for SIMADYN D industrial serial communication and process automation.
Product Type:	SS4 Communication Module for CS7 support module.
System Compatibility:	Compatible with Siemens SIMADYN D systems and CS7 communication support modules.
Communication Protocols:	Supports DUST1, DUST2, DUST3, and USS communication protocols for industrial networking.
Physical Interfaces:	Standard RS-232 interface with optional RS-485 and 20 mA TTY interface modules for flexible communication.
Supported Devices:	Connects engineering PCs, SIMATIC S5 PLCs, OP2 operator panels, VD1 displays, printers, and Siemens drive converters.
Data Exchange:	Utilizes 16 KB dual-port RAM through the CS7 support module for high-speed communication with CPU modules.
Maximum Baud Rate:	Supports communication speeds up to 187.5 kbaud, depending on protocol and interface configuration.
Dimensions:	22 × 70 × 184 mm (W × H × D).
Weight:	Approx. 0.2 kg.
