Siemens 6DP1230-7AA FUM 230 analog encoder preparation module In stock

Siemens 6DP1230-7AA FUM 230 analog encoder preparation module In stock

Product Name:FUM 230 analog encoder preparation module

Brand Name:Siemens

Model Number:6DP1230-7AA

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6dp1230 7aa fum 230 analog encoder preparation module in stock-1

Overview
Contact us
Specifications
Description
Applications
Technical Data Summary
Environmental Strength
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6DP1230-7AA
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact us

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model:	6DP1230-7AA, Siemens FUM 230 analog encoder preparation module designed for industrial analog signal acquisition and conditioning.
Product Type:	Analog Encoder Preparation Module supporting process instrumentation and automation control applications.
Analog Inputs:	16 configurable analog input channels supporting 0/4–20 mA current signals in both 2-wire and 4-wire configurations.
Encoder Power Supply:	Integrated 24 V DC supply for connected field transmitters and analog encoders.
Signal Processing:	Supports signal correction, improving measurement precision and long-term stability.
Diagnostic Functions:	Monitors encoder supply, wire break, measuring range overshoot, and undershoot for enhanced operational reliability.
Redundant Operation:	Suitable for redundant system architectures to maximize process availability.
Dimensions:	Approx. 233 × 160 × 20 mm (H × D × W), compact rack-mounted industrial module.
Net Weight:	Approximately 0.55 kg.
Country of Origin:	Germany.
Product Status:	Discontinued product (PLM PM500), commonly used for maintenance and replacement of installed Siemens systems.

Description

The 6DP1230-7AA is a Siemens FUM 230 analog encoder preparation module engineered for precise acquisition and conditioning of industrial analog signals. Featuring 16 configurable inputs supporting 0/4–20 mA current signals in both 2-wire and 4-wire configurations, it delivers reliable measurement performance for demanding process automation systems. Integrated 24 V DC encoder power supply simplifies field device connection while ensuring stable signal transmission.

Designed for continuous industrial operation, the 6DP1230-7AA incorporates advanced diagnostic capabilities including encoder supply supervision, wire-break detection, measuring range overshoot and undershoot monitoring, and signal correction functions. These features help improve measurement accuracy, minimize downtime, and increase the reliability of critical automation processes.

Compatible with Siemens automation environments including TELEPERM, SIMATIC, and related process control platforms, the 6DP1230-7AA is well suited for power generation, chemical processing, metallurgy, and other industries requiring accurate analog signal conditioning. Although this model has reached its product lifecycle, it remains a trusted solution for maintaining and upgrading existing industrial control systems.
