Product Name: SIMATIC ET 200SP DI 8x24VDC High Feature Input Module
Brand Name: Siemens
Model Number: 6ES7131-6BF00-0CA0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
| Sales | Phone/Whatsapp | |
| Jim Pei | [email protected] | +86 18020776782 |
| Official article number | 6ES7131-6BF00-0CA0 |
| Manufacturer | Siemens AG |
| Product family | SIMATIC ET 200SP |
| Firmware version | V1.2 |
| usable BaseUnits | BU type A0 |
| Color code for module-specific color identification plate | CC01 |
| I&M data | Yes |
| STEP 7 TIA Portal configurable/integrated as of version | V12 SP1 / V13 |
| STEP 7 configurable/integrated as of version | V5.5 SP3 / - |
| PROFIBUS as of GSD version/GSD revision | GSD Revision 5 |
| PROFINET as of GSD version/GSD revision | V2.3 / - |
| MSI | Yes |
| Rated value (DC) | 24 V |
| permissible range, lower limit (DC) | 19.2 V |
| permissible range, upper limit (DC) | 28.8 V |
| Reverse polarity protection | Yes |
| 6ES7131-6BF00-0CA0 | subject to modifications |
| Number of outputs | 8 |
| 24 V | Yes |
| Short-circuit protection | Yes |
| Output current, max. | 700 mA |
| Power loss, typ. | 1.5 W |
| Address space per module, max. | 1 byte ; + 1 byte for QI information |
| Number of digital inputs | 8 |
| Input characteristic curve in accordance with IEC 61131, type | Yes |
| Pulse extension | Yes |
| Length | 50 ms, 100 ms, 200 ms, 500 ms, 1 s, 2 s |
| Type of input voltage | DC |
| Rated value, DC | 24 V |
| for signal "0" | -30 to +5 V |
| for signal "1", typ. | 2.5 mA |
| parameterizable | Yes ; 0.05 / 0.1 / 0.4 / 0.8 / 1.6 / 3.2 / 12.8 / 20 ms (in each case + |
| parameterizable | Yes |
| Cable length, shielded, max. | 1000 m |
| Cable length unshielded, max. | 600 m |
| 2-wire sensor | Yes |
| permissible quiescent current (2-wire sensor), max. | 1.5 mA |
| Isochronous mode (application synchronized up to terminal) | Yes |
| Filtering and processing time (TCI), min. | 420 µs |
| Bus cycle time (TDP), min. | 500 µs |
| Jitter, max. | 8 µs |
| Diagnostic alarm | Yes |
| Hardware interrupt | Yes |
| Diagnostics | Yes |
| Monitoring the supply voltage | Yes |
| Wire-break | Yes |
| Short-circuit | Yes |
| Monitoring the supply voltage (PWR-LED) | Yes ; green PWR LED |
| Channel status display | Yes ; Green LED |
| for channel diagnostics | Yes ; Red LED |
| for module diagnostics | Yes ; green/red DIAG LED |
| between the channels | No |
| between the channels and the backplane bus | Yes |
| between different circuits | 75 V DC/60 V AC (base isolation) |
| Isolation tested with | 707 V DC (type test) |
6ES7131-6BF00-0CA0 is a Siemens SIMATIC ET 200SP DI 8x24VDC High Feature Input Module with eight digital inputs. Its official product data identifies 24 V DC operation and channel diagnostics. This Siemens SIMATIC ET 200SP product is engineered for dependable integration into compatible industrial automation systems. It supports clear product identification for engineering, replacement, and maintenance workflows. The genuine Siemens article helps maintain consistent system architecture and organized spare-parts planning. For sourcing and lifecycle support, 6ES7131-6BF00-0CA0 is a precisely identified Siemens industrial automation solution.
