Siemens 6ES7132-4BD00-0AA0 5 ELECTRON MODULES FOR ET 200S Original new

Siemens 6ES7132-4BD00-0AA0 5 ELECTRON MODULES FOR ET 200S Original new

Product Name:5 ELECTRON MODULES FOR ET 200S

Brand Name:Siemens

Model Number:6ES7132-4BD00-0AA0

Country of Origin:Germany

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7132 4bd00 0aa0 5 electron modules for et 200s original new-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7132-4BD00-0AA0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Description
Product Model	6ES7132-4BD00-0AA0
Product Type	Digital Output Module (ET 200S)
Output Channels	4 DO
Rated Voltage	24 V DC
Output Current	0.5 A per channel
Power Loss	0.8 W (typ.)
Switching Frequency	up to 100 Hz (resistive load)
Cable Length	up to 1000 m (shielded)
Protection	Short-circuit protected
Isolation	500 V DC tested
Width	15 mm
Height	81 mm
Depth	52 mm
Weight	approx. 40 g

Description

The 6ES7132-4BD00-0AA0 is a SIMATIC DP ET 200S digital output module designed for reliable 24 V DC switching applications in distributed automation systems. It provides four standard digital outputs with 0.5 A output current per channel, ensuring stable and efficient load control in industrial environments. Its compact 15 mm design allows high-density installation within ET 200S stations.

Built for durability, 6ES7132-4BD00-0AA0 supports fast switching performance with microsecond-level response times, making it suitable for high-speed control tasks. The module offers short-circuit protection and integrated diagnostics through LED status indication, improving system safety and maintenance efficiency.

As part of the Siemens ET 200S series, 6ES7132-4BD00-0AA0 integrates seamlessly into PROFIBUS-based distributed I/O architectures. It is widely used in factory automation, machine control systems, and process industries requiring compact, modular, and dependable output solutions.

Applications

Power plants: Used for generator set status monitoring and relay protection.
Substations: Enable switchgear control, circuit signaling, and protection systems.
Chemical plants: Support automated process control and safe signal switching.
Steel mills: Provide reliable output control in high-temperature and EMI-heavy environments.
Machinery manufacturing: Used in production lines, robotic control systems, and packaging automation.

Features

Compact 15 mm slim module design
4-channel 24 V DC digital output
Short-circuit and overload protection
Fast switching response for automation control
LED diagnostics for real-time status monitoring
High cable length flexibility up to 1000 m
Designed for ET 200S distributed I/O systems

Functions

Digital ON/OFF output control
Load switching for actuators and relays
Integration into PROFIBUS automation networks
Fault indication via diagnostic LEDs
Safe operation under industrial electrical noise conditions

FAQ

Q1: What is the main function of 6ES7132-4BD00-0AA0?
A1: It provides 4-channel 24 V DC digital output control for ET 200S automation systems.

Q2: Is the module protected against short circuits?
A2: Yes, each output channel includes integrated short-circuit protection.

Q3: What is the output current per channel?
A3: Each channel supports a rated output current of 0.5 A.

Q4: Can it be used in long-distance wiring systems?
A4: Yes, it supports up to 1000 m shielded cable length.

Q5: What industries commonly use this module?
A5: It is widely used in power plants, factories, chemical plants, and machinery automation systems.
