Siemens 6ES7134-0KH01-0XB0 SIMATIC ET 200B Analog Input Electronic Module

Siemens 6ES7134-0KH01-0XB0 SIMATIC ET 200B Analog Input Electronic Module

Product Name: SIMATIC ET 200B Analog Input Electronic Module

Brand Name: Siemens

Model Number: 6ES7134-0KH01-0XB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp: +86 18020776782

Email: [email protected]

Overview
Contact info
Description
Specifications
Commercial Term
FAQ
Other Products
Recommended Products

Protect sensor wiring and measurement setup during an ET 200B exchange

An ET 200B analog electronic module for eight thermocouple inputs or four Pt100 inputs, with 12-bit resolution.

Before you order: Confirm the existing terminal block, sensor type, input range and PROFIBUS configuration before a spare is fitted.

Contact info

CONTACT

Jim Pei

[email protected]

+86 180 2077 6782

Description

This Siemens ET 200B module serves temperature and related analog measurement points. Its channel allocation differs between thermocouple and Pt100 applications, so a visible eight-channel housing does not identify the configured sensor mode.

Record the installed module and terminal block, the original channel parameterization and sensor wiring. After exchange, compare values against a known reference and review diagnostics before returning process control to automatic operation.

Monitoring & Control

Check measurement range and sensor wiring against the original ET 200B configuration. A swapped thermocouple polarity or mismatched RTD connection can produce misleading process values.

Installation & Integration

Preserve the PROFIBUS address and station configuration. Confirm the required TB8 terminal block and 24 V DC supply from the original installation.

Specifications

Product family

SIMATIC ET 200B

Module type

Analog input electronic module

Input arrangement

8 thermocouple or 4 Pt100 inputs

Resolution

12 bit

Required terminal block

TB8

Supply

24 V DC nominal

Fieldbus

PROFIBUS DP

Commercial Term

Quotation

Current price and availability

Payment

T/T or agreed terms

Lead time

Confirmed with quotation

Shipping

DHL, FedEx, UPS or agreed freight

Warranty

12 months

FAQ

How can I verify 6ES7134-0KH01-0XB0 for my installed ET 200B station?

Compare the complete module label, TB8 terminal block, sensor types and station configuration. Record the original wiring and parameter set before ordering.

Why might temperatures be implausible after replacing 6ES7134-0KH01-0XB0?

Check thermocouple polarity, Pt100 wiring, channel type and range settings. Compare one channel with a known reference before adjusting process alarms.

What should I preserve before removing 6ES7134-0KH01-0XB0?

Save the ET 200B station configuration and diagnostic history, label each sensor lead and photograph the terminal block. Record compensation and limit settings used by the application.

What should I inspect if 6ES7134-0KH01-0XB0 shows a bus fault?

Confirm the station supply, PROFIBUS cabling, address and termination, then compare the configured module identity with the installed part. Review the master diagnostics.

How should I investigate a wire-break alarm on 6ES7134-0KH01-0XB0?

Identify the affected channel in diagnostics, inspect the sensor and terminals, and compare the channel parameterization with the actual thermocouple or RTD circuit.

What information should a buyer provide for 6ES7134-0KH01-0XB0?

Send the complete order number, module and terminal-block photos, installed sensor types, condition requirements and whether the current station configuration is available.
