Siemens 6ES7135-4FB00-0AB0 Analog Output Module

Siemens 6ES7135-4FB00-0AB0 Analog Output Module

Product Name: Analog Output Module

Brand Name: Siemens

Model Number: 6ES7135-4FB00-0AB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7135 4fb00 0ab0 analog output module-1

Overview
Commercial Terms
Description
Functions
Specifications
Advantage
Applications & Use Cases
Product Recommendations
Recommended Products

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The Siemens 6ES7135-4FB00-0AB0 Analog Output Module is a high-performance output module designed for the SIMATIC ET 200S distributed I/O system. Featuring two analog voltage output channels in a compact 15 mm-wide housing, it enables precise control of industrial devices such as drives, valves, actuators, and process equipment. The module supports voltage output ranges including ±10 V with high-resolution signal conversion, ensuring accurate and stable control performance.

Engineered for demanding automation applications, the module offers fast response times with cycle times below 1.5 ms, integrated diagnostic capabilities through the SF (System Fault) LED, and reliable electrical isolation. Its compact design, high accuracy, and seamless integration with SIMATIC systems make it an ideal choice for distributed control architectures requiring precise analog signal output.

Functions

Provides 2 analog voltage output channels.
Supports precise voltage signal generation for industrial control applications.
Delivers high-resolution analog output for accurate process control.
Controls actuators, drives, valves, and other analog devices.
Supports fast signal updates with cycle times up to 1.5 ms.
Includes SF LED indication for diagnostic and fault monitoring.
Provides electrical isolation for improved system safety.
Integrates seamlessly into ET 200S distributed I/O stations.
Enables communication through the SIMATIC backplane bus architecture.

Specifications

Product Name	Siemens 6ES7135-4FB00-0AB0 Analog Output Module
Manufacturer	Siemens
Product Type	Analog Output Module
Part Number	6ES7135-4FB00-0AB0
Place of shipment	Xiamen, China
Country of origin	Germany
Rated value (DC)	24 V; From power module
from load voltage L+ (without load), max.	130 mA
from backplane bus 3.3 V DC, max	10 mA
Power loss, max.	2 W
Address space per module, max.	4 byt
Number of analog outputs	2
Voltage output, short-circuit current, max.	25 mA
Cycle time (all channels) max.	1.5 ms
between MANA and M internally (UISO)	75 V DC/60 V AC
Isolation tested with	500 V DC

Advantage

The Siemens 6ES7135-4FB00-0AB0 combines compact design, fast response, and precise analog output performance. Compared with standard analog output modules, it offers improved control accuracy, faster processing, and efficient integration into distributed automation systems.

High-Precision Analog Output
Supports accurate voltage signal generation for demanding control and regulation tasks.

Fast Response Performance
Cycle times below 1.5 ms enable rapid output updates and improved process responsiveness.

Compact Space-Saving Design
15 mm module width helps maximize cabinet space utilization in distributed I/O systems.

Integrated Diagnostics
SF LED status indication allows quick identification of system faults and operational conditions.

Reliable Electrical Isolation
Isolation tested up to 500 V DC enhances system protection and operational reliability.

Seamless ET 200S Integration
Designed specifically for SIMATIC ET 200S systems, simplifying installation and engineering.

Low Power Consumption
Efficient operation minimizes energy usage while maintaining high performance.

Applications & Use Cases

Industrial process control systems
Variable frequency drive (VFD) control
Valve positioning and regulation applications
Actuator and servo control systems
Packaging and production machinery
Chemical and pharmaceutical processing plants
Water and wastewater treatment facilities
Energy and utility automation systems
Distributed I/O architectures using ET 200S
Factory automation and machine control applications

The Siemens 6ES7135-4FB00-0AB0 Analog Output Module is ideal for applications requiring precise and reliable analog voltage output. Its fast response, compact footprint, and robust industrial design make it an excellent solution for modern automation systems that demand accurate process control and high system availability.
