Siemens 6ES7135-4GB00-0AB0 ELECTRONIC MODULE FOR ET 200S Ready For Ship

Siemens 6ES7135-4GB00-0AB0 ELECTRONIC MODULE FOR ET 200S Ready For Ship

Product Name:ELECTRONIC MODULE FOR ET 200S

Brand Name:Siemens

Model Number:6ES7135-4GB00-0AB0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7135 4gb00 0ab0 electronic module for et 200s ready for ship-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7135-4GB00-0AB0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6ES7135-4GB00-0AB0
Manufacturer	Siemens
Product Series	ET 200S
Product Type	Electronic Analog Output Module
Output Channels	2 AO
Signal Range	±20 mA / 4–20 mA
Resolution	Up to 14-bit
Conversion Time	< 1 ms cycle time
Load Resistance	Max. 500 Ω
Power Supply	24 V DC (via power module)
Backplane Voltage	3.3 V DC
Power Loss	Max. 2 W
Cable Length (Shielded)	Up to 200 m
Diagnostic Function	Wire-break, group fault
LED Indicator	SF (group fault)
Dimensions	15 × 81 × 52 mm
Weight	approx. 0.04 kg
Isolation Voltage	500 V DC

Description

The Siemens 6ES7135-4GB00-0AB0 is a compact electronic analog output module designed for the ET 200S distributed I/O system. It delivers high-precision current output signals for industrial automation and process control applications, ensuring stable performance in fast-cycle control environments.

The 6ES7135-4GB00-0AB0 provides 2 analog output channels supporting ±20 mA and 4–20 mA signal ranges with up to 14-bit resolution. With a cycle time of less than 1 ms, it enables fast and accurate signal conversion for dynamic control processes. The module supports diagnostic functions including wire-break detection and group fault indication via LED SF.

As part of Siemens ET 200S distributed I/O architecture, the 6ES7135-4GB00-0AB0 is widely used in process automation, machine control, and industrial field systems requiring precise analog signal output and reliable real-time performance.

Applications

Power Plants: Used for turbine control, generator regulation, and analog signal output in automation systems.
Substations: Supports control signal transmission for protection and switching systems.
Chemical Plants: Enables precise process control, dosing systems, and instrumentation output.
Steel Mills: Ensures stable analog control in high temperature and strong electromagnetic environments.
Machinery Manufacturing Plants: Used in robotics, automation lines, and precision equipment control.
Oil & Gas Facilities: Supports valve positioning, flow control, and process regulation systems.
Water Treatment Plants: Used for pump control, chemical dosing, and distributed process automation.

Features

2-channel analog current output module
Supports ±20 mA and 4–20 mA signals
Ultra-compact 15 mm module width
High-speed cycle time < 1 ms
Up to 14-bit resolution precision output
Integrated diagnostic and fault detection
LED SF group fault indication
Designed for ET 200S distributed I/O systems

Functions

Converts digital signals into analog current outputs
Provides precise process control signals
Supports real-time industrial automation tasks
Enables distributed field device control
Detects wire-break and system faults
Ensures stable and accurate signal transmission
Enhances system response speed and reliability

FAQ

Q1: What is the main function of Siemens 6ES7135-4GB00-0AB0?
A1: It is an ET 200S analog output module used for precise current signal control.

Q2: How many output channels does it provide?
A2: It provides 2 analog output channels.

Q3: What signal types are supported?
A3: It supports ±20 mA and 4–20 mA current output ranges.

Q4: Does it support diagnostic functions?
A4: Yes, it includes wire-break detection and group fault diagnostics.

Q5: What systems is it compatible with?
A5: It is designed for Siemens ET 200S distributed I/O systems.
