Product Name: ET 200iSP 4F-DQ Ex(i) Fail-Safe Electronic Module
Brand Name: Siemens
Model Number: 6ES7138-7FD00-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
| Product Name | Siemens 6ES7138-7FD00-0AB0 ET 200iSP 4F-DQ Ex(i) Fail-Safe Electronic Module |
| Manufacturer | Siemens |
| Product Type | ET 200iSP 4F-DQ Ex(i) Fail-Safe Electronic Module |
| Part Number | 6ES7138-7FD00-0AB0 |
| Estimated shipping dimensions | |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Number of Digital Outputs | 4 |
| Digital Output Type | Transistor |
| Output Rating | 17.4 V DC / 40 mA |
| Explosion Protection | Ex i (Intrinsically Safe) |
| Permissible Supply Voltage Range | 19.2–30 V DC |
| Typical Current Consumption | 340 mA |
| Maximum Current from Load Voltage L+ | 510 mA without load, internal power bus |
| Maximum Power Loss | 5.3 W |
| Fieldbus Connection | Via separate transceiver |
| Short-Circuit Protection | Yes |
| No-Load Output Voltage Uao | 17.4 V DC |
| Internal Resistance Ri | 167 Ω |
| Load Resistance Range | 270 Ω–18 kΩ |
| Trend Point Voltage Ue | 10.7 V DC |
| Trend Point Current Ie | 40 mA |
| Maximum Output Voltage for Signal “1” | 17.4 V |
| Permissible Output Voltage | 0–17.4 V |
| Residual Current for Signal “0” | Max. 10 µA |
| Parallel Outputs for Increased Power | Yes |
| Parallel Outputs for Redundant Load Control | No |
| Maximum Switching Frequency – Resistive Load | 30 Hz |
| Maximum Switching Frequency – Inductive Load | 2 Hz |
| Maximum Shielded Cable Length | 500 m |
| Maximum Unshielded Cable Length | 500 m |
| Diagnostic Information | Readable |
| Wire-Break Diagnostics | Yes |
| Short-Circuit Diagnostics | Yes |
| Group Error Indicator | SF, Red LED |
| Digital Output Status Indicator | Green LED |
| Channel-to-Channel Isolation | No |
| Channel-to-Backplane Bus Isolation | Yes |
| Channel-to-Load Voltage L+ Isolation | Yes |
| Permissible Potential Difference | 60 V DC / 30 V AC |
| Isolation Test | 370 V for 1 minute |
| Degree of Protection | IP20 |
| CE Mark | Yes |
| Suitable for Safety Functions | Yes |
| Electrical Connection | Screw / Spring-Type Terminal |
|
Sales |
|
Phone/Whatsapp |
|
Jim Pei |
The Siemens 6ES7138-7FD00-0AB0 ET 200iSP 4F-DQ Ex(i) Fail-Safe Electronic Module is a 4-channel intrinsically safe fail-safe digital output module designed for the SIMATIC ET 200iSP distributed I/O platform. It provides four transistor outputs rated at 17.4 VDC / 40 mA and is designed for Ex i intrinsically safe circuits, making it suitable for safety-related control in hazardous process environments. The module incorporates short-circuit and wire-break diagnostics, readable diagnostic information, output status LEDs, and electrical isolation from both the backplane bus and load supply. With support for safety functions and cable lengths up to 500 m, it provides reliable control of compatible field devices in demanding process automation and hazardous-area installations.
The Siemens 6ES7138-7FD00-0AB0 is designed for fail-safe switching of intrinsically safe field devices in hazardous industrial environments. Its four Ex(i) transistor outputs can be used with compatible low-power actuators, signaling devices, interface components, and other intrinsically safe loads requiring dependable safety-related output control. Integrated wire-break and short-circuit diagnostics help identify field circuit faults and support reliable operation of safety instrumented applications.
As part of the SIMATIC ET 200iSP platform, the module is particularly suitable for process industries such as oil and gas, petrochemical processing, chemical manufacturing, pharmaceutical production, and other facilities with potentially explosive atmospheres. Its combination of intrinsic safety, fail-safe output control, electrical isolation, and comprehensive diagnostics enables decentralized installation close to process equipment while supporting plant safety, system availability, and efficient maintenance.
