Siemens 6ES7141-5AF00-0BA0 SIMATIC ET 200AL Digital Input Module

Siemens 6ES7141-5AF00-0BA0 SIMATIC ET 200AL Digital Input Module

Product Name: SIMATIC ET 200AL Digital Input Module

Brand Name: Siemens

Model Number: 6ES7141-5AF00-0BA0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7141 5af00 0ba0 simatic et 200al digital input module-1

Overview
Specifications
Commercial Terms
Description
Functions
Why Choose US
FAQ
Other Products
Recommended Products

Contact Info

Sales:	Email:	Whatsapp:
Jim Pei	[email protected]	+86 18020776782

Specifications

Product Name	Siemens 6ES7141-5AF00-0BA0 SIMATIC ET 200AL Digital Input Module
Manufacturer	Siemens
Product Type	SIMATIC ET 200AL Digital Input Module
Part Number	6ES7141-5AF00-0BA0
Place of shipment	Xiamen, China
Country of origin	Germany
Rated Voltage	24 VDC
Input Voltage Range	20.4～28.8 VDC
Reverse Connection Protection	Supported
No-load Current	25 mA
1L+ Maximum Current	4 A
2L+ Maximum Current	4 A
Encoder Power Output	4 Channels
Output Voltage	24 VDC
Maximum Output Current	0.7 A (Total)
Typical Power Consumption	1.9 W
Number of Input Points	8
Maximum Simultaneous Input	8 Points (≤55°C)
Input Voltage	24 VDC
OFF State	-30～+5 V
ON State	+11～+30 V
Typical Input Current (ON State)	3.2 mA
Operating Temperature	-30～+55°C
Protection Rating	IP65 / IP67
I/O Interface	M12, 5-pin
Power Interface	M8, 4-pin
ET Connection	M8, 4-pin, Shielded
Maximum Unshielded Cable Length	30 m
Maximum Static Current of Two-Wire Sensor	1.5 mA

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The 6ES7141-5AF00-0BA0 SIMATIC ET 200AL Digital Input Module is a rugged distributed digital input module designed for the Siemens ET 200AL I/O system. It provides eight 24 VDC digital input channels for reliable acquisition of signals from sensors, switches, and other field devices. Featuring an IP65/IP67 protection rating, M12 and M8 industrial connectors, reverse polarity protection, and a compact design, the module is ideal for decentralized automation installations in harsh industrial environments without requiring an additional control cabinet.

Functions

Acquires 24 VDC digital input signals from industrial sensors and field devices.
Provides eight digital input channels for monitoring switches, push buttons, proximity sensors, and limit switches.
Converts field input signals into digital data for Siemens PLC and ET 200AL automation systems.
Supports decentralized I/O installation close to machines and production equipment.
Features IP65/IP67 protection for reliable operation in harsh industrial environments.
Provides reverse connection protection to help safeguard the module during installation.
Supplies encoder power through integrated 24 VDC output channels.
Uses industrial M12 and M8 connectors for fast and reliable field wiring.
Supports simultaneous monitoring of all eight input channels under normal operating conditions.
Ideal for machine automation, material handling, packaging systems, assembly lines, and factory automation applications.

Why Choose US

✔ Genuine Industrial Automation Products
✔ Strict Quality Inspection Before Shipment
✔ Competitive Prices & Flexible Quotations
✔ Large Inventory with Fast Global Shipping
✔ 12-Month Warranty on Eligible Products
✔ Professional Technical & After-Sales Support
✔ Inquiry Response Within 1 Hour
✔ Secure Packaging for International Shipping
✔ Trusted Supplier for PLC, DCS, HMI, and Industrial Control Systems

FAQ

Q1: What is the 6ES7141-5AF00-0BA0 SIMATIC ET 200AL Digital Input Module used for?
A: The 6ES7141-5AF00-0BA0 is used to acquire 24 VDC digital signals from industrial sensors and switches in Siemens ET 200AL distributed automation systems.

Q2: How many digital inputs does the 6ES7141-5AF00-0BA0 provide?
A: The 6ES7141-5AF00-0BA0 provides eight digital input channels.

Q3: What input voltage does the 6ES7141-5AF00-0BA0 support?
A: The 6ES7141-5AF00-0BA0 operates with a rated input voltage of 24 VDC and an input voltage range of 20.4 VDC to 28.8 VDC.

Q4: Does the 6ES7141-5AF00-0BA0 provide reverse polarity protection?
A: Yes. The 6ES7141-5AF00-0BA0 includes reverse connection protection to help prevent damage caused by incorrect wiring.

Q5: What protection rating does the 6ES7141-5AF00-0BA0 have?
A: The 6ES7141-5AF00-0BA0 is rated IP65/IP67, making it suitable for demanding industrial environments.

Q6: What connectors are used on the 6ES7141-5AF00-0BA0?
A: The 6ES7141-5AF00-0BA0 uses M12 5-pin connectors for I/O connections and M8 4-pin connectors for power supply and ET communication.
