Siemens 6ES7144-4FF01-0AB0 SIMATIC DP ET 200pro 4 AI U High Feature Analog Input Electronic Module

Siemens 6ES7144-4FF01-0AB0 SIMATIC DP ET 200pro 4 AI U High Feature Analog Input Electronic Module

Product Name: SIMATIC DP ET 200pro 4 AI U High Feature Analog Input Electronic Module

Brand Name: Siemens

Model Number: 6ES7144-4FF01-0AB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7144 4ff01 0ab0 simatic dp et 200pro 4 ai u high feature analog input electronic module-1

Overview
Specifications
Commercial Terms
Description
Features
FAQ
After-sales Service
Major Business
Recommended Products

Contact Info

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Specifications

Product Name	Siemens 6ES7144-4FF01-0AB0 SIMATIC DP ET 200pro 4 AI U High Feature Analog Input Electronic Module
Manufacturer	Siemens
Product Type	SIMATIC DP ET 200pro 4 AI U High Feature Analog Input Electronic Module
Part Number	6ES7144-4FF01-0AB0
Place of shipment	Xiamen, China
Country of origin	Germany
Rated Supply Voltage	24 V DC
Reverse Polarity Protection	Yes, against destruction
Current from Supply Voltage 1L+	40 mA max., typical
Current from 3.3 V DC Backplane Bus	12 mA max., typical
Encoder Supply Outputs	4
Encoder Supply Short-Circuit Protection	Yes, per module, electronic to frame
Encoder Supply Output Current	1 A max. up to 55 °C
Typical Power Loss	1.1 W
Address Space	8 bytes max.
Number of Analog Inputs	4
Maximum Permissible Input Voltage	35 V
Maximum Cycle Time	5 ms, all channels
Voltage Input Ranges	0 to +10 V; 1 to 5 V; -10 to +10 V; -5 to +5 V
Maximum Shielded Cable Length	30 m
Measurement Principle	Integrating
Maximum Resolution	15 bit; 15 bit + sign at ±10 V and ±5 V; 15 bit at 0–10 V and 1–5 V
Interference Frequency Suppression	16.67 / 50 / 60 / 3600 Hz
Signal Encoder Connection	Voltage measurement supported
Linearity Error	±0.0075% of input range
Temperature Error	±0.00075%/K of input range
Crosstalk Between Inputs	-70 dB min.
Repeat Accuracy at 25 °C	±0.004% of input range
Operational Error Limit	±0.1% of input range
Basic Error Limit at 25 °C	±0.075% of input range
Series Mode Interference Suppression	60 dB min.
Common Mode Interference Suppression	80 dB min.; interference voltage <10 V
Diagnostic Functions	Yes
Diagnostic Alarm	Yes, parameterizable
Hardware Interrupt	Yes; limit value alarm, parameterizable for channel 0
Diagnostic Information Readable	Yes
Wire-Break Diagnostics	Yes, at 1–5 V
Short-Circuit Diagnostics	Yes, at 1–5 V
Diagnostic LED	SF group error, red
Channel-to-Channel Isolation	No
Channel-to-Backplane Bus Isolation	Yes
Permissible Potential Difference (Inputs to MANA)	10 Vpp AC
Isolation Test Voltage	707 V DC (type test)

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The Siemens 6ES7144-4FF01-0AB0 is a SIMATIC DP ET 200pro High Feature analog input electronic module designed for precise voltage signal acquisition in distributed automation systems. It features 4 analog input channels, supports multiple measurement ranges including 0–10 V, 1–5 V, ±10 V, and ±5 V, and provides resolution up to 15 bit + sign. With high measurement accuracy, integrated diagnostic functions, and sensor supply capability, the module enables reliable collection and processing of signals from industrial sensors and measuring devices. It is well suited for machine automation, process monitoring, production equipment, test systems, and other applications requiring stable and accurate analog data acquisition.

Features

Provides 4 analog voltage input channels for industrial signal acquisition.
Supports 0 to +10 V, 1 to 5 V, -10 to +10 V, and -5 to +5 V input ranges.
Offers measurement resolution up to 15 bit + sign for bipolar voltage ranges.
Maximum cycle time of 5 ms for all channels supports responsive signal processing.
Provides 4 integrated encoder supply outputs.
Encoder supply outputs feature electronic short-circuit protection.
Supports up to 1 A encoder supply output current at temperatures up to 55°C.
High measurement accuracy with a basic error limit of ±0.075% at 25°C.
Integrating measurement principle supports stable analog signal acquisition.
Provides strong series-mode and common-mode interference suppression.
Supports parameterizable diagnostic alarms for improved system monitoring.
Provides a parameterizable limit-value hardware interrupt for channel 0.
Supports wire-break and short-circuit diagnostics when using the 1–5 V range.
Red SF LED provides clear group error indication.
Provides electrical isolation between the analog channels and backplane bus.

FAQ

1. Does the Siemens 6ES7144-4FF01-0AB0 support wire-break diagnostics?
Yes. The Siemens 6ES7144-4FF01-0AB0 supports wire-break diagnostics when operating with the 1–5 V input range.

2. Does the Siemens 6ES7144-4FF01-0AB0 support hardware interrupts?
Yes. The Siemens 6ES7144-4FF01-0AB0 supports a parameterizable limit-value hardware interrupt for channel 0.

3. What is the maximum cycle time of the Siemens 6ES7144-4FF01-0AB0?
The Siemens 6ES7144-4FF01-0AB0 has a maximum cycle time of 5 ms when processing all analog input channels.

4. How many analog inputs does the Siemens 6ES7144-4FF01-0AB0 provide?
The Siemens 6ES7144-4FF01-0AB0 provides 4 analog input channels for voltage measurement.

5. What input ranges does the Siemens 6ES7144-4FF01-0AB0 support?
The Siemens 6ES7144-4FF01-0AB0 supports 0 to +10 V, 1 to 5 V, -10 to +10 V, and -5 to +5 V input ranges.

6. Where is the Siemens 6ES7144-4FF01-0AB0 typically used?
The Siemens 6ES7144-4FF01-0AB0 is suitable for machine automation, production lines, process monitoring, test equipment, material handling systems, and other industrial applications requiring accurate voltage signal acquisition.
