Siemens 6ES7147-4JD00-0AB0 SIMATIC DP ET 200pro 4 IO-Link High Feature Electronic Module

Siemens 6ES7147-4JD00-0AB0 SIMATIC DP ET 200pro 4 IO-Link High Feature Electronic Module

Product Name: SIMATIC DP ET 200pro 4 IO-Link High Feature Electronic Module

Brand Name: Siemens

Model Number: 6ES7147-4JD00-0AB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7147 4jd00 0ab0 simatic dp et 200pro 4 io link high feature electronic module-1

Overview
Product Parameters
Commercial Terms
Contact Us
Why Choose US
Major Business
Product Feature
FAQ
Recommended Products

Overview

The Siemens 6ES7147-4JD00-0AB0 SIMATIC DP ET 200pro 4 IO-Link High Feature Electronic Module is a high-performance IO-Link electronic module designed for the SIMATIC ET 200pro distributed I/O system. It features four IO-Link master ports, all of which can operate simultaneously, supporting IO-Link V1.0 and V1.1 communication at speeds up to 230.4 kBaud (COM3). With flexible IO-Link, digital input, and digital output operating modes, advanced diagnostics, and IP65/IP67 protection, the module delivers reliable device connectivity and efficient field-level communication for industrial automation applications.

Product Parameters

Product Name	Siemens 6ES7147-4JD00-0AB0 SIMATIC DP ET 200pro 4 IO-Link High Feature Electronic Module
Manufacturer	Siemens
Product Type	SIMATIC DP ET 200pro 4 IO-Link High Feature Electronic Module
Part Number	6ES7147-4JD00-0AB0
Place of shipment	Xiamen, China
Country of origin	Germany
Rated Supply Voltage	24 V DC
Reverse Polarity Protection	Yes
Load Voltage (2L+)	24 V DC
Load Voltage Protection	Short-Circuit and Reverse Polarity Protected
Current Consumption (1L+)	Max. 40 mA
Current Consumption (2L+, No Load)	Max. 20 mA
Backplane Bus Current	Max. 20 mA @ 3.3 V DC
Encoder Supply Outputs	4
Maximum Output Current	2 A (Up to +55 °C)
Typical Power Dissipation	2.6 W
IO-Link Ports	4
Simultaneously Active Ports	4
Supported IO-Link Versions	IO-Link V1.0, V1.1
Transmission Rates	COM1: 4.8 kBaud, COM2: 38.4 kBaud, COM3: 230.4 kBaud
Process Data Size	32 Bytes Input / 32 Bytes Output per Port
Parameter Memory	2 KB per Port
Configuration	Autostart / Manual, Without S7-PCT
Maximum Cable Length	20 m (Unshielded)
Operating Modes	IO-Link, Digital Input (DI), Digital Output (DQ)
Digital Output Current	Max. 100 mA per Port
Port Types	Type A and Type B
Additional Device Supply	2 A Total (X1/X2), 2 A Total (X3/X4)
Diagnostics	Channel Diagnostics, Diagnostic Alarms, Wire-Break Detection, Short-Circuit Detection
Status Indicators	Channel Status LED, SF (Red), Fault (Red)
Isolation	Backplane Bus Isolated from All Other Circuits
Isolation Test Voltage	707 V DC
Protection Rating	IP65/IP67
Safety Function	Not Suitable for Safety-Related Tripping

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales:	Email:	Whatsapp:
Jim Pei	[email protected]	+86 18020776782

Why Choose US

✔ Genuine Industrial Automation Products
✔ Strict Quality Inspection Before Shipment
✔ Competitive Prices & Flexible Quotations
✔ Large Inventory with Fast Global Shipping
✔ 12-Month Warranty on Eligible Products
✔ Professional Technical & After-Sales Support
✔ Inquiry Response Within 1 Hour
✔ Secure Packaging for International Shipping
✔ Trusted Supplier for PLC, DCS, HMI, and Industrial Control Systems

Major Business

ABB: Industrial robot parts of DSQC series,Bailey INFI90, DCS
Honeywell: 51/MU/MC/TC/CC ...
Triconex: 3008/3511/3625/3664/3721/3700A..
Bently Nevada: 3500/3300/330180-Cable..
Foxboro: FBM203/204/217/231, FCP240/270
Woodward: SPC valve position controller, PEAK15 digital controller
Siemens: 6DD/6DP/6ES5/6DR/6GK Series
Westinghouse Series: 1C/5X ...
General electric: IC693/IC697/IC695/DS200..
Schneider: 140 Series

Product Feature

Four IO-Link Master Ports
Provides four independently operating IO-Link ports with simultaneous communication capability.
Supports IO-Link V1.0 and V1.1
Compatible with multiple IO-Link device versions for flexible integration into automation systems.
Multiple Operating Modes
Each port can operate as an IO-Link interface, digital input, or digital output to suit various applications.
High-Speed Communication
Supports COM1 (4.8 kBaud), COM2 (38.4 kBaud), and COM3 (230.4 kBaud) transmission rates.
Advanced Diagnostics
Includes channel diagnostics, diagnostic alarms, wire-break detection, and short-circuit detection for improved system reliability.
Generous Process Data Capacity
Supports up to 32 bytes of input and 32 bytes of output process data per port with 2 KB parameter memory.
Industrial-Grade Protection
Features IP65/IP67 protection and electrical isolation between the backplane bus and all other circuits.
Reliable Power Distribution
Provides integrated encoder supply outputs with reverse polarity and short-circuit protection for connected devices.

FAQ

---What is the 6ES7147-4JD00-0AB0 used for?
6ES7147-4JD00-0AB0 is used to connect and manage IO-Link devices, digital inputs, and digital outputs in SIMATIC ET 200pro distributed I/O systems.

---How many IO-Link ports does the 6ES7147-4JD00-0AB0 provide?
6ES7147-4JD00-0AB0 provides four IO-Link master ports that can all operate simultaneously.

---Which IO-Link versions are supported by the 6ES7147-4JD00-0AB0?
6ES7147-4JD00-0AB0 supports both IO-Link V1.0 and IO-Link V1.1 devices.

---What communication speeds are available on the 6ES7147-4JD00-0AB0?
6ES7147-4JD00-0AB0 supports COM1 at 4.8 kBaud, COM2 at 38.4 kBaud, and COM3 at 230.4 kBaud.

---What operating modes does the 6ES7147-4JD00-0AB0 support?
6ES7147-4JD00-0AB0 supports IO-Link, digital input (DI), and digital output (DQ) operating modes.

---What is the maximum cable length for the 6ES7147-4JD00-0AB0?
6ES7147-4JD00-0AB0 supports unshielded IO-Link cable lengths of up to 20 meters.

---What diagnostics are available on the 6ES7147-4JD00-0AB0?
6ES7147-4JD00-0AB0 provides channel diagnostics, diagnostic alarms, wire-break detection, and short-circuit detection.
