Siemens 6ES7194-4CA00-0AA0 SIMATIC DP connection module In stock

Siemens 6ES7194-4CA00-0AA0 SIMATIC DP connection module In stock

Product Name:SIMATIC DP connection module

Brand Name:Siemens

Model Number:6ES7194-4CA00-0AA0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7194 4ca00 0aa0 simatic dp connection module in stock-1

Overview
Contact us
Specifications
Description
Applications
Control & Communication
Environment and Certification
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7194-4CA00-0AA0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact us

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6ES7194-4CA00-0AA0
Product Name	SIMATIC DP Connection Module
Manufacturer	Siemens
Product Type	Connection Module for ET 200 PRO
Series	SIMATIC ET 200 PRO
Compatible Modules	Digital and Analog Electronic Modules
Connection Interface	4 × M12 Connectors
Communication System	PROFIBUS DP
Installation	Distributed I/O Connection Module
Function	Signal and Field Device Connection
Mechanical Design	Compact Modular Construction
Dimensions	45 × 130 × 39 mm
Weight	Approx. 300 g

Description

The 6ES7194-4CA00-0AA0 is a Siemens SIMATIC DP connection module developed for the ET 200 PRO distributed I/O platform. Designed to accommodate both digital and analog electronic modules, it provides a dependable interface for industrial field connections through four integrated M12 ports, helping simplify installation while maintaining reliable signal transmission.

As part of the SIMATIC ET 200 PRO family, the 6ES7194-4CA00-0AA0 supports modular automation architectures that require flexible expansion and efficient field-level connectivity. It integrates seamlessly with PROFIBUS DP systems and is suitable for decentralized control cabinets, machine automation, and distributed I/O applications across demanding industrial environments.

With its compact mechanical design, rugged construction, and straightforward module integration, the 6ES7194-4CA00-0AA0 improves wiring efficiency, reduces maintenance time, and enhances overall system reliability for manufacturing, process automation, material handling, and industrial production facilities.

Applications

Power plants: Provides reliable field wiring for distributed I/O stations, supporting generator monitoring, protection systems, and process signal transmission.
Substations: Connects decentralized digital and analog modules for switchgear automation, protection relays, and equipment monitoring.
Chemical plants: Enables secure field-level communication between process instruments and ET 200 PRO distributed control systems.
Steel mills: Supports stable signal connections for rolling lines, furnaces, conveyors, and heavy-duty industrial automation equipment.
Machinery manufacturing plants: Simplifies machine wiring for robotic systems, automated assembly lines, packaging equipment, and production cells.
Water treatment facilities: Connects field sensors and actuators for pumping stations, filtration units, and process control networks.
Automotive manufacturing: Provides dependable distributed I/O connectivity for flexible production lines and automated testing equipment.

Control & Communication

Supports seamless integration with Siemens SIMATIC ET 200 PRO distributed I/O systems.
Compatible with PROFIBUS DP communication architecture.
Four integrated M12 connectors simplify field wiring.
Supports both digital and analog electronic modules.
Modular design enables flexible system expansion.
Helps reduce wiring complexity and installation time.
Reliable signal transmission improves control system stability.
Suitable for decentralized industrial automation networks.

Environment and Certification

Rugged industrial design suitable for continuous factory operation.
Compact enclosure saves installation space inside automation systems.
High mechanical durability for demanding industrial environments.
Reliable operation in applications exposed to vibration and electrical noise.
Designed for long service life with minimal maintenance.
Fully compatible with Siemens ET 200 PRO modular architecture.
Manufactured to international industrial quality standards.
Classification references include eClass, ETIM, IDEA, and UNSPSC, simplifying engineering selection and asset management.

FAQ

Q1: What is the 6ES7194-4CA00-0AA0 used for?
A1: It is a connection module designed for Siemens ET 200 PRO systems, providing field connections for digital and analog electronic modules.

Q2: Which automation platform supports the 6ES7194-4CA00-0AA0?
A2: It is designed specifically for the Siemens SIMATIC ET 200 PRO distributed I/O platform.

Q3: How many field connectors are available on the 6ES7194-4CA00-0AA0?
A3: The module features four integrated M12 connectors for fast and reliable field device connections.

Q4: Is the 6ES7194-4CA00-0AA0 compatible with analog and digital modules?
A4: Yes. It supports both digital and analog electronic modules within the ET 200 PRO system.

Q5: What industries commonly use the 6ES7194-4CA00-0AA0?
A5: It is widely applied in power generation, chemical processing, manufacturing, water treatment, steel production, logistics automation, and machine building.
