Siemens 6ES7214-1BD23-0XB0 SIMATIC S7-200 CPU 224 programmable logic controller Ready For Ship

Siemens 6ES7214-1BD23-0XB0 SIMATIC S7-200 CPU 224 programmable logic controller Ready For Ship

Product Name:SIMATIC S7-200 CPU 224 programmable logic controller

Brand Name:Siemens

Model Number:6ES7214-1BD23-0XB0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7214 1bd23 0xb0 simatic s7 200 cpu 224 programmable logic controller ready for ship-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7214-1BD23-0XB0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model:	6ES7214-1BD23-0XB0, SIMATIC S7-200 CPU 224 Compact PLC.
Product Type:	Compact programmable logic controller with integrated AC power supply and relay outputs.
Digital Inputs:	14 integrated 24 V DC digital input channels with parameterizable input delay.
Digital Outputs:	10 integrated relay outputs rated up to 2 A per output.
Memory Capacity:	12 KB program memory and 8 KB data memory with battery backup support.
Communication:	Integrated MPI and PPI interfaces with serial communication and PROFIBUS DP expansion capability.
Expansion Capacity:	Supports up to 7 expansion modules, 168 digital I/O points, and 35 analog I/O channels.
Protection Rating:	IP20 enclosure designed for industrial control cabinet installation.
Dimensions:	120.5 × 80 × 62 mm, compact housing for space-efficient automation systems.
Weight:	Approximately 410 g, durable industrial-grade controller for continuous operation.

Description

The Siemens 6ES7214-1BD23-0XB0 is a compact SIMATIC S7-200 CPU 224 programmable logic controller designed for reliable machine control and small to medium-sized automation systems. Featuring an integrated AC power supply, 14 digital inputs, and 10 relay outputs, it combines processing capability and flexible I/O in a single compact unit, making it ideal for space-constrained control cabinets.

As a member of the SIMATIC S7-200 PLC family, 6ES7214-1BD23-0XB0 provides 12 KB program memory, 8 KB data memory, high-speed counters, multiple communication interfaces, and support for PROFIBUS DP expansion. Its scalable architecture allows easy integration of additional digital and analog modules to meet changing application requirements.

Built for industrial reliability, 6ES7214-1BD23-0XB0 is widely used in manufacturing equipment, conveyor systems, packaging machinery, water treatment facilities, HVAC systems, and general industrial automation where dependable control, flexible expansion, and long-term operational stability are essential.

Applications

Power plants: Used for auxiliary equipment control, generator monitoring, and process automation tasks.
Substations: Supports local equipment control, status monitoring, and communication with supervisory systems.
Chemical plants: Controls pumps, valves, dosing equipment, and process automation devices with reliable PLC logic.
Steel mills: Executes machine sequencing, conveyor control, and production equipment automation in demanding environments.
Machinery manufacturing plants: Integrates automated production lines, robotic workstations, packaging machines, and assembly equipment.
Water treatment facilities: Controls pumps, filtration systems, chemical dosing units, and remote process monitoring.

Features

Compact PLC with integrated AC power supply.
14 digital inputs and 10 relay outputs.
12 KB program memory and 8 KB data memory.
Supports PROFIBUS DP system expansion.
Expandable with digital and analog I/O modules.
Integrated MPI and PPI communication interfaces.
High-speed counters and configurable timers.
Reliable industrial design with battery-backed memory.

Functions

Executes PLC logic for industrial machine automation.
Monitors digital input signals from field devices.
Controls relays, motors, valves, and actuators.
Supports serial communication with HMIs and external equipment.
Expands system capacity through additional I/O modules.
Processes high-speed counting and timing applications.
Provides reliable control for continuous industrial operations.

FAQ

Q1: What is the main function of 6ES7214-1BD23-0XB0?
A1: It is a compact PLC that provides machine control, digital I/O processing, and communication for industrial automation systems.

Q2: How many integrated I/O channels does 6ES7214-1BD23-0XB0 include?
A2: The controller features 14 digital inputs and 10 relay digital outputs in a single compact unit.

Q3: Does 6ES7214-1BD23-0XB0 support system expansion?
A3: Yes. It supports up to seven expansion modules, allowing additional digital and analog I/O as application requirements grow.

Q4: Which communication interfaces are available on 6ES7214-1BD23-0XB0?
A4: The CPU includes integrated MPI and PPI communication interfaces and supports PROFIBUS DP expansion.

Q5: What industries commonly use 6ES7214-1BD23-0XB0?
A5: It is widely used in manufacturing, packaging, water treatment, power generation, HVAC, conveyor systems, and general industrial automation applications.
