Siemens SIMATIC S7-1200F 6ES7215-1AF40-0XB0 CPU 1215 FC Compact CPU DC/DC/DC

Siemens SIMATIC S7-1200F 6ES7215-1AF40-0XB0 CPU 1215 FC Compact CPU DC/DC/DC

SIEMENS · SIMATIC S7-1200F 6ES7215-1AF40-0XB0 CPU 1215 FC Compact CPU DC/DC/DC	Fail-safe CPU CPU 1215 FC 2 PROFINET ports
Digital I/O: 14 DI / 10 DO · Analog I/O: 2 AI / 2 AO · Memory: 250 KB
Order check: Confirm the complete article number, firmware, safety engineering and application before quotation. Email Inquiry WhatsApp [email protected] \| +86 18159889985

Overview
Applications
Data
Construction
Environment
Selection
Verification
Commercial
Models
Recommended Products

Official product overview

6ES7215-1AF40-0XB0 CPU 1215 FC compact fail-safe CPU

The Siemens 6ES7215-1AF40-0XB0 is a SIMATIC S7-1200F CPU 1215 FC compact fail-safe CPU. Siemens specifies a DC/DC/DC design, two PROFINET ports, fourteen 24 V DC digital inputs, ten 24 V DC 0.5 A digital outputs, two analog inputs, two analog outputs, a 20.4 to 28.8 V DC supply range and 250 KB program/data memory.

Lifecycle note: Commercial availability, condition and delivery status are subject to verification.

Applications

System role

Fail-safe control with onboard I/O and PROFINET

Fail-safe and standard automation tasks engineered within a verified SIMATIC S7-1200F system.
Compact control using integrated digital I/O plus two analog inputs and two analog outputs.
PROFINET-connected automation using two onboard ports with topology confirmed during engineering.
Projects requiring the CPU 1215 FC memory and I/O profile documented by Siemens.

Selection note: Safety suitability and system coordination must be confirmed before quotation.

Data

Siemens data sheet

Key technical values

Use the exact article number and the official Siemens data sheet when validating a project.

Product type	CPU 1215FC DC/DC/DC
Firmware version	V4.7
Engineering software	STEP 7 V20 or higher
Supply	20.4 to 28.8 V DC
Digital I/O	14 DI 24 V DC; 10 DO 24 V DC, 0.5 A
Analog I/O	2 AI 0 to 10 V DC; 2 AO 0 to 20 mA DC
Communication	2 PROFINET ports
Program/data memory	250 KB

Construction

Integrated fail-safe CPU, I/O and PROFINET

The compact CPU integrates processing, DC supply, digital and analog I/O, safety functions and two PROFINET ports. Expansion, terminal and mounting choices must be verified for the engineered safety system.

Interface check: Confirm terminal allocation, output loads, analog ranges, safety parameters, network topology and expansion hardware.

Environment

Protection and environment

Installation conditions

Apply the limits and approvals stated for the exact Siemens article.

Operating temperature	Confirm the permitted range and mounting-position limits in the current Siemens data sheet
Storage and transport	Subject to verification
Humidity and altitude	Confirm before quotation
Protection and approvals	Request current Siemens certificates for the destination and application

Engineering note: Use current Siemens safety and system documentation for installation restrictions.

Selection

System role

Installation and selection sequence

Match the complete 6ES7215-1AF40-0XB0 article number and exact CPU variant.
Confirm the power supply, output loads and onboard analog signal ranges.
Verify TIA Portal / STEP 7 version, CPU firmware and safety engineering requirements.
Check expansion modules, signal boards, communication modules, mounting and certificate requirements.

Selection note: Do not infer compatibility from a similar family designation.

Verification

Before order

Verification checklist

Complete article number and suffix	CPU firmware and STEP 7 version
Safety engineering requirements	DC supply and output loads
Analog I/O ranges	PROFINET topology and expansion
Current unit and nameplate photographs	Condition, testing, warranty, stock and dispatch terms

Match firmware, safety project, DC loads, network and expansion hardware before approval.

Commercial

Written confirmation

Commercial information before payment

Every commercial commitment is confirmed against the exact article and quoted unit.

Stock status	Confirm before quotation for the exact article number and requested quantity.
Condition	New, used or refurbished status is stated in the written quotation.
Photos / nameplate	Current unit and nameplate photos are available on request.
Test statement	Available on request and subject to the agreed test scope.
Warranty	Confirmed in the formal quotation.
Dispatch	Confirmed after stock, destination and order approval are verified.
Payment	Supported methods are listed in the formal quotation.
Quote response	Subject to verification and request completeness.
Transaction trust	Seller details, quotation, invoice and payment instructions are available for review before payment.
Product status	Actual stock, condition, testing, warranty and dispatch are subject to verification.
