Product Name: SM 1223 Digital I/O Module
Brand Name: Siemens
Model Number: 6ES7223-1BH32-0XB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Overview
The Siemens 6ES7223-1BH32-0XB0 is a compact digital I/O expansion module designed for Siemens SIMATIC S7-1200 PLC systems. The module integrates 8 digital inputs and 8 digital outputs operating at 24 V DC, providing reliable signal acquisition and control for industrial automation applications. Its compact size, low power consumption, and stable electrical performance make it suitable for machine control, process automation, and compact PLC installations.
Designed to expand the functionality of S7-1200 controllers, the SM 1223 module offers efficient digital signal processing while maintaining reliable operation under industrial working conditions.
|
Sales |
|
|
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7223-1BH32-0XB0 SM 1223 Digital I/O Module |
| Manufacturer | Siemens |
| Product Type | SM 1223 Digital I/O Module |
| Part Number | 6ES7223-1BH32-0XB0 |
| Estimated shipping dimensions | 4.4x7.4x9.9cm |
| Weight | 0.18kg |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Product type designation | SM 1223, DI 8x24 V DC, DQ 8x24 V DC |
| Rated value (DC) | 24 V |
| permissible range, lower limit (DC) | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V |
| from backplane bus 5 V DC, max | 145 mA |
| from load voltage L+ (without load), max. | 4 mA; per channel |
| for signal \\\\ | 5 V DC at 1 mA |
| for signal \\\\ | 15 V DC at 2.5 mA |
The Siemens 6ES7223-1BH32-0XB0 is suitable for various industrial automation and machine control applications, including:
Its compact size makes it especially suitable for installations with limited cabinet space.
The Siemens 6ES7223-1BH32-0XB0 is designed for stable operation in industrial automation environments. It operates with a 24 V DC supply voltage and supports a permissible voltage range from 20.4 V to 28.8 V DC, ensuring reliable performance under varying power conditions. The module features low power consumption and efficient signal processing, enabling continuous long-term operation in industrial control cabinets and automation systems. Its robust construction and compatibility with Siemens S7-1200 controllers ensure dependable operation in demanding factory and process automation environments.
