Product Name: Digital I/O MODULE
Brand Name: Siemens
Model Number: 6ES7223-1BL30-0XB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Overview
The Siemens 6ES7223-1BL30-0XB0 is a digital I/O module designed for the SIMATIC S7-1200 automation platform. It combines 16 digital inputs and 16 digital transistor outputs within a single compact module, providing efficient signal acquisition and output control for industrial automation systems.
This module is designed to expand the input and output capabilities of S7-1200 PLCs while reducing installation space and wiring complexity. Its integrated digital I/O configuration makes it suitable for machine automation, production equipment, and process control applications requiring fast and reliable signal handling.
The 6ES7223-1BL30-0XB0 supports standard 24V DC industrial control signals and offers flexible sink/source input compatibility. With transistor-based outputs delivering fast switching performance, the module is well-suited for high-speed automation tasks and modern industrial control systems.
|
Sales |
|
|
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7223-1BL30-0XB0 Digital I/O MODULE |
| Manufacturer | Siemens |
| Product Type | Digital I/O MODULE |
| Part Number | 6ES7223-1BL30-0XB0 |
| Estimated shipping dimensions | 7x7.5x10cm |
| Weight | 0.26kg |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| permissible range, lower limit (DC) | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V |
| Rated value DC | 24 V |
| for signal \\\\ | 5 VDC at 1 mA |
| for signal \\\\ | 15 VDC at 2.5 mA |
| Digital Inputs | 16 DI |
| Input Voltage | 24 V DC |
| Input Type | Sink/Source |
| Digital Outputs | 16 DO |
| Output Type | Transistor |
| Output Current | 0.5 A per output |
The Siemens 6ES7223-1BL30-0XB0 digital I/O module is designed for installation in industrial control cabinets as part of the SIMATIC S7-1200 automation system. The module is typically mounted on standard DIN rails and operates using a stable 24V DC industrial power supply.
The module is intended for use in factory automation and process control environments where reliable digital signal acquisition and output control are required. Its sink/source compatible inputs and transistor outputs make it suitable for connection with a wide variety of industrial sensors, switches, actuators, and control devices.
Engineered for continuous industrial operation, the module can withstand electrical interference, vibration, and demanding operating conditions commonly found in manufacturing facilities. Its compact modular design supports efficient installation in space-limited control panels while maintaining stable and dependable performance over long operating periods.
