Siemens 6ES7313-5BF03-0AB0 SIMATIC S7-300 CPU 313C Original new

Siemens 6ES7313-5BF03-0AB0 SIMATIC S7-300 CPU 313C Original new

Product Name:SIMATIC S7-300 CPU 313C

Brand Name:Siemens

Model Number:6ES7313-5BF03-0AB0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7313 5bf03 0ab0 simatic s7 300 cpu 313c original new-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7313-5BF03-0AB0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6ES7313-5BF03-0AB0
Product Series	SIMATIC S7-300 CPU 313C
Product Type	Compact Central Processing Unit (CPU)
Working Memory	64 KB integrated
Digital Inputs	24 DI
Digital Outputs	16 DO
Analog Inputs	4 AI + 1 Pt100 Temperature Input
Analog Outputs	2 AO
High-Speed Counters	3 channels, up to 30 kHz
Supply Voltage	24 VDC (20.4–28.8 VDC)
Communication Interface	Integrated MPI (RS485)
Programming Software	STEP 7 V5.3 SP2 or later
Load Memory	Micro Memory Card (MMC), up to 8 MB
Dimensions	120 × 125 × 130 mm
Weight	Approx. 660 g

Description

6ES7313-5BF03-0AB0 is a compact and versatile CPU from the Siemens SIMATIC S7-300 family, engineered for small and medium-sized industrial automation systems. Integrating 24 digital inputs, 16 digital outputs, 4 analog inputs, 2 analog outputs, one Pt100 temperature input, and three 30 kHz high-speed counters, it combines PLC processing and onboard I/O into a single compact unit, reducing cabinet space and simplifying system design.

Designed for use with STEP 7 V5.3 SP2 or later, the 6ES7313-5BF03-0AB0 features 64 KB of working memory, an integrated MPI communication interface, and Micro Memory Card support for secure program storage and maintenance-free data retention. Its high-speed execution and built-in technological functions make it well suited for motion control and process automation tasks.

With integrated PID control, pulse outputs, analog signal processing, and reliable diagnostic capabilities, the 6ES7313-5BF03-0AB0 delivers dependable performance for packaging equipment, conveyor systems, machine tools, water treatment facilities, and general factory automation requiring compact yet powerful PLC control.

Applications

Power plants: Controls auxiliary equipment, monitors process signals, and supports generator automation.
Substations: Collects field signals, manages local automation equipment, and interfaces with supervisory control systems.
Chemical plants: Executes process control, analog signal acquisition, and temperature monitoring in continuous production.
Steel mills: Performs high-speed equipment control and reliable digital/analog processing in demanding industrial environments.
Machinery manufacturing plants: Operates automated production lines, robotic stations, packaging machines, and conveyor systems.
Water treatment facilities: Controls pumps, valves, dosing systems, and process instrumentation.
Food and beverage industry: Supports filling, mixing, packaging, and production line automation.

Features

Compact PLC with integrated digital and analog I/O.
Built-in Pt100 temperature measurement channel.
Three 30 kHz high-speed counters for motion applications.
Integrated PID control and pulse output functions.
Supports Micro Memory Card for reliable program storage.
Fast instruction execution for responsive machine control.
Compatible with Siemens STEP 7 engineering software.
Maintenance-free data retention and comprehensive diagnostics.

Functions

Logic Control: Executes automation programs with stable and deterministic PLC performance.
Signal Acquisition: Processes digital, analog, and temperature signals in real time.
Motion Control: Supports high-speed counting and pulse output for positioning applications.
Process Regulation: Implements PID control for temperature, pressure, and flow management.
Communication: Exchanges data with HMIs and engineering stations via the integrated MPI interface.
System Diagnostics: Provides operating status monitoring and fault diagnostics to simplify maintenance.

FAQ

Q1: What is the main purpose of the 6ES7313-5BF03-0AB0?
A1: The 6ES7313-5BF03-0AB0 is a compact PLC CPU designed for machine automation and industrial process control with integrated digital and analog I/O.

Q2: How many onboard I/O channels are included?
A2: It provides 24 digital inputs, 16 digital outputs, 4 analog inputs, 2 analog outputs, and 1 Pt100 temperature input.

Q3: Does the CPU support high-speed counting?
A3: Yes. It includes three integrated high-speed counters operating at frequencies up to 30 kHz.

Q4: Which programming software is compatible with this CPU?
A4: The module is programmed using Siemens STEP 7 V5.3 SP2 or later with the required hardware updates.

Q5: What applications are best suited for the 6ES7313-5BF03-0AB0?
A5: It is ideal for packaging equipment, conveyor systems, machine tools, water treatment plants, process automation, and compact industrial control systems.
