Product Name: CPU MODULE
Brand Name: SIEMENS
Model Number: 6ES7313-6BG04-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7313-6BG04-0AB0 CPU MODULE |
| Manufacturer | SIEMENS |
| Product Type | CPU MODULE |
| Part Number | 6ES7313-6BG04-0AB0 |
| Weight | 0.64 kg |
| Estimated shipping dimensions | 12x12.4x12.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| HW functional status | 1 |
| Firmware version | V3.3 |
| Rated value (DC) | 24 V |
| permissible range, lower limit (DC) | 19.2 V |
| permissible range, upper limit (DC) | 28.8 V |
| Mains/voltage failure stored energy time | 5 ms |
| Repeat rate, min. | 1 s |
| Current consumption (rated value) | 580 mA |
| Current consumption (in no-load operation), typ. | 110 m |
| AInrush current, typ. | 5 A |
| I²t | 0.7 A²·s |
| Communication Interface | MPI |
| Serial Interface | RS485 |
| Digital Inputs | 16 DI |
| Digital Outputs | 16 DO |
| High-Speed Counters | 3 high-speed counters (30 kHz) |
| Power Supply | Integrated 24 VDC |
| Work Memory | 128 KB |
| Industrial Control Processor | Embedded Control CPU |
| Automation CPU Unit | High-Speed Counter CPU |
| Siemens S7 Controller | Siemens PLC Hardware |
| Compact PLC CPU | Distributed Control CPU |
| Integrated I/O CPU Module | Industrial Electronics CPU |
| Industrial Automation Controller | Process Control CPU |
| PLC Central Processing Unit | Machine Control CPU |
| Factory Automation CPU | Siemens Automation System |
The 6ES7313-6BG04-0AB0 is a Siemens S7-300 series CPU module designed for industrial automation and machine control applications. It integrates processing power, communication interfaces, and built-in I/O capabilities into a compact control unit.
With integrated 16 digital inputs, 16 digital outputs, and high-speed counters, this CPU provides a cost-efficient solution for medium-scale automation systems. It supports MPI and RS485 communication, making it suitable for distributed control environments and industrial networking.
Central Processing Control
Executes automation programs and controls all system logic operations in S7-300 PLC architectures.
Integrated Digital I/O Processing
Provides 16 digital inputs and 16 digital outputs for direct field device control.
High-Speed Counting
Supports up to 3 high-speed counters at 30 kHz for motion and pulse signal processing.
Industrial Communication Handling
Enables communication via MPI and RS485 interfaces for PLC networking and programming.
System Memory Execution
Utilizes 128 KB work memory for program execution and data handling.
Real-Time Control Operation
Ensures fast and deterministic control response for industrial processes.
Power Supply Integration
Operates with integrated 24 VDC power supply for simplified system design.
Fault Tolerance Handling
Includes energy buffering (5 ms) for stable operation during voltage fluctuations.
Compared with similar compact PLC CPUs, the 6ES7313-6BG04-0AB0 offers integrated I/O, high-speed counters, and flexible communication interfaces, making it suitable for cost-effective and space-saving automation systems.
Integrated CPU and I/O Design: Combines processing and I/O in one module, reducing system complexity.
Built-In High-Speed Counters: Supports fast pulse processing up to 30 kHz for motion control applications.
Flexible Communication Options: Includes MPI and RS485 interfaces for industrial networking.
Compact PLC Architecture: Reduces cabinet space requirements while maintaining full functionality.
Reliable Real-Time Performance: Ensures stable execution of automation logic and control tasks.
Energy Buffer Protection: Maintains operation during short voltage interruptions.
Cost-Effective Control Solution: Reduces need for additional I/O modules and hardware components.
How many I/O points does 6ES7313-6BG04-0AB0 have?
The 6ES7313-6BG04-0AB0 includes 16 digital inputs and 16 digital outputs.
What communication interfaces does 6ES7313-6BG04-0AB0 support?
The 6ES7313-6BG04-0AB0 supports MPI and RS485 communication interfaces.
Does 6ES7313-6BG04-0AB0 support high-speed counting?
Yes, the 6ES7313-6BG04-0AB0 supports 3 high-speed counters up to 30 kHz.
What is the work memory of 6ES7313-6BG04-0AB0?
The 6ES7313-6BG04-0AB0 has 128 KB of work memory.
What power supply does 6ES7313-6BG04-0AB0 use?
The 6ES7313-6BG04-0AB0 operates on a 24 VDC integrated power supply.
What happens during a power interruption in 6ES7313-6BG04-0AB0?
The 6ES7313-6BG04-0AB0 provides a 5 ms energy buffer to maintain stable operation during short voltage drops.
