Product Name: CENTRAL PROCESSING UNIT
Brand Name: Siemens
Model Number: 6ES7318-3FL00-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7318-3FL00-0AB0 CENTRAL PROCESSING UNIT |
| Manufacturer | Siemens |
| Product Type | CENTRAL PROCESSING UNIT |
| Part Number | 6ES7318-3FL00-0AB0 |
| Weight | 1.25kg |
| Estimated shipping dimensions | 12x12x12.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Power Supply Voltage | 24V DC |
| Power Buffer | Main power/voltage fault storage time: 5 ms |
| Input Current | 1250 mA |
| Power Consumption | 14W |
| Operating Temperature Range | 0°C to +60°C |
| Humidity Range | 5% to 95% (non-condensing) |
| Programming Languages | KOP, FUP, AVIL, SCL |
| Hardware product version | 3 |
| Firmware version | V2.8 |
| permissible range, lower limit (DC) | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V |
| external protection for power supply lines(recommendation) | 2 A min |
| Current consumption (rated value) | 1050 mA |
| Current consumption (in no-load operation), typ | 400 mA |
| Inrush current, typ | 4 A |
| Plug-in (MMC), max | 8 Mbyte |
| Number of connections | 32 |
| Transmission rate, max. | 12 Mbit/s |
The Siemens 6ES7318-3FL00-0AB0 is a high-performance SIMATIC S7-300 CPU 319F-3 PN/DP fail-safe central processing unit designed for both standard and safety-related automation tasks. It integrates powerful processing capabilities with multi-protocol communication, making it suitable for complex and mission-critical industrial applications where reliability, safety integrity, and real-time performance are essential.
The Siemens 6ES7318-3FL00-0AB0 combines standard PLC control with SIL 3 safety functionality (IEC 61508), enabling unified control of safety and non-safety processes within a single controller. With support for MPI/DP, PROFIBUS DP, and PROFINET Ethernet communication, it ensures seamless integration into modern industrial networks while delivering high computing performance and extensive diagnostic capabilities for continuous 24/7 operation.
The primary function of the Siemens 6ES7318-3FL00-0AB0 is to execute both safety-related and standard automation programs while managing communication and control across complex industrial systems.
Key functions include:
Compared with conventional PLC CPUs and basic safety controllers, the Siemens 6ES7318-3FL00-0AB0 delivers higher performance, integrated safety functionality, and superior communication capabilities within a single platform.
1. Integrated Safety and Standard Control
The Siemens 6ES7318-3FL00-0AB0 combines fail-safe and standard automation in one CPU, eliminating the need for separate safety controllers.
2. High Safety Integrity (SIL 3)
Unlike standard PLC CPUs, the Siemens 6ES7318-3FL00-0AB0 meets SIL 3 requirements, making it suitable for high-risk industrial applications.
3. Powerful Multi-Protocol Communication
With support for MPI/DP, PROFIBUS DP, and PROFINET, it provides more flexible connectivity than many legacy controllers.
4. High Processing Performance
The Siemens 6ES7318-3FL00-0AB0 offers strong computing capability and large memory capacity (2.5 MB), enabling complex automation and safety logic execution.
5. Industrial-Grade Reliability
Designed for continuous 24/7 operation, it ensures stable performance in demanding environments such as automotive, chemical, and energy industries.
6. Advanced Diagnostics and System Transparency
Built-in diagnostics improve fault detection and system transparency compared to conventional PLC systems, reducing downtime and maintenance effort.
Q1: Does 6ES7318-3FL00-0AB0 support safety functions?
A: Yes, the Siemens 6ES7318-3FL00-0AB0 is a fail-safe CPU with SIL 3 certification, suitable for safety-critical applications.
Q2: Which communication protocols are supported by 6ES7318-3FL00-0AB0?
A: The Siemens 6ES7318-3FL00-0AB0 supports MPI/DP, PROFIBUS DP, and PROFINET communication protocols.
Q3: What industries commonly use 6ES7318-3FL00-0AB0?
A: The Siemens 6ES7318-3FL00-0AB0 is commonly used in automotive manufacturing, chemical processing, power plants, and pharmaceutical production.
Q4: What programming languages are supported by 6ES7318-3FL00-0AB0?
A: The Siemens 6ES7318-3FL00-0AB0 supports KOP, FUP, AWL, and SCL programming languages.
Q5: Why choose 6ES7318-3FL00-0AB0 over a standard PLC CPU?
A: The Siemens 6ES7318-3FL00-0AB0 offers integrated safety (SIL 3), higher processing power, and multi-protocol communication, making it suitable for complex and safety-critical automation systems.
