Siemens 6ES7334-0KE00-0AB0 SIMATIC S7-300 SM 334 Analog Module

Siemens 6ES7334-0KE00-0AB0 SIMATIC S7-300 SM 334 Analog Module

Product Name: SIMATIC S7-300 SM 334 Analog Module

Brand Name: Siemens

Model Number: 6ES7334-0KE00-0AB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7334 0ke00 0ab0 simatic s7 300 sm 334 analog module-1

Overview
Specifications
Contact Us
Overview
Functions
Why Choose Us
Major Business
After-sales Service
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Specifications

Product Name	Siemens 6ES7334-0KE00-0AB0 SIMATIC S7-300 SM 334 Analog Module
Manufacturer	Siemens
Product Type	SIMATIC S7-300 SM 334 Analog Module
Part Number	6ES7334-0KE00-0AB0
Place of shipment	Xiamen, China
Country of origin	Germany
Analog Inputs	4
Voltage Inputs	2
Resistance Inputs	4
Analog Outputs	2
Resolution	12-bit
Rated Supply Voltage	24 VDC
Reverse Polarity Protection	Yes
Input Current (L+, Max.)	80 mA
Backplane Bus Current	60 mA at 5 VDC
Typical Power Loss	2 W
Voltage Input Range	0 to 10 V
Maximum Permissible Input Voltage	20 V Continuous, 75 V for Max. 1 s
Resistance Thermometer	Pt100 (Climatic Range -120 to 155°C)
Resistance Measurement Range	0 to 10 kΩ
Constant Measurement Current	490 µA (Pt100), 105 µA (10 kΩ)
Input Cycle Time	Max. 85 ms
Voltage Input Resistance	100 kΩ
Maximum Shielded Cable Length (Input)	100 m
Voltage Output Range	0 to 10 V
Maximum Short-Circuit Current	30 mA
Minimum Load Impedance	2.5 kΩ
Maximum Capacitive Load	1 µF
Maximum Shielded Cable Length (Output)	100 m
Output Conversion Time	500 µs per Channel
Output Settling Time	0.8 ms (Resistive Load), 0.8 ms (Capacitive Load)
Integration Time	16.67 ms / 20 ms (Parameterizable)
Interference Suppression Frequency	50 / 60 Hz
Supported Resistance Connection	2-wire, 3-wire, 4-wire
Resistance Accuracy (Operating Temperature)	±3.5% of Input Range (10 kΩ)
Isolation Test Voltage	500 VDC
Required Front Connector	20-pin

Contact Us

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Overview

The Siemens 6ES7334-0KE00-0AB0 SIMATIC S7-300 SM 334 Analog Module is a versatile analog input/output module designed for the SIMATIC S7-300 automation platform. It features 4 analog inputs, 2 analog outputs, 12-bit resolution, 24 VDC supply voltage, and supports voltage, resistance, and Pt100 temperature measurement with configurable 2-wire, 3-wire, and 4-wire connections. Designed to provide precise analog signal acquisition and output control, the module enhances process accuracy, simplifies field device integration, and delivers dependable long-term performance. It is an ideal solution for process automation, manufacturing, machine control, water treatment, chemical processing, and other industrial control applications.

Functions

Multi-Signal Analog Acquisition
Collects analog voltage, resistance, and Pt100 RTD signals from field devices, providing accurate process measurements for industrial monitoring and control.

Analog Output Control
Generates analog voltage output signals for controlling actuators, variable-speed drives, valves, and other analog-controlled industrial equipment.

Temperature Measurement Support
Supports direct connection of Pt100 resistance temperature sensors with 2-wire, 3-wire, and 4-wire configurations, enabling reliable temperature monitoring in process applications.

Resistance Measurement
Measures resistance values over a wide range, allowing the module to interface with resistive sensors used in industrial process and equipment monitoring.

Signal Conditioning and Noise Suppression
Performs analog signal conversion with configurable integration times and 50/60 Hz interference suppression, ensuring stable measurements even in electrically noisy industrial environments.

Seamless S7-300 Integration
Integrates directly with Siemens SIMATIC S7-300 PLC systems, providing dependable analog data acquisition and output control for manufacturing, process automation, water treatment, chemical processing, and machine control applications.
