Siemens 6ES7341-1AH02-0AE0 Serial Communications Module

Siemens 6ES7341-1AH02-0AE0 Serial Communications Module

Product Name: Serial Communications Module

Brand Name: Siemens

Model Number: 6ES7341-1AH02-0AE0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7341 1ah02 0ae0 serial communications module-1

Overview
Commercial Terms
Specifications
Description
Functions
Features
Advantage
FAQ
Recommended Products

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Specifications

Product Name	Siemens 6ES7341-1AH02-0AE0 Serial Communications Module
Manufacturer	Siemens
Product Type	Serial Communications Module
Part Number	6ES7341-1AH02-0AE0
Weight	0.24kg
Estimated shipping dimensions	4x11.6x12.5cm
Place of shipment	Xiamen, China
Country of origin	Germany
Rated value (DC)	24 V DC
from supply voltage L+, max.	100 mA
from backplane bus 5 V DC, max.	70 mA
Power loss, typ	1.6 W
Power loss, max.	2.4 W
Number of interfaces	1; Isolated
Interface physics, RS 232C (V.24)	Yes
Transmission rate, min.	0.3 kbit/s
Transmission rate, max.	115.2 kbit/s
Cable length, max	15 m
Connector type	9-pin sub D connector

Description

The Siemens 6ES7341-1AH02-0AE0 is a serial communications module designed for integration into Siemens S7-300 automation systems. It provides a single isolated RS-232C (V.24) interface, enabling reliable serial data exchange between a PLC and external devices such as printers, barcode scanners, HMIs, or third-party industrial equipment. With a 24 V DC supply requirement and optimized power consumption, it ensures stable communication performance in industrial control environments.

The Siemens 6ES7341-1AH02-0AE0 is engineered for flexible serial communication with transmission rates ranging from 0.3 kbit/s to 115.2 kbit/s and a maximum cable length of 15 meters. Its isolated interface design enhances signal integrity and protects the PLC system from electrical interference. Compact construction and robust Siemens engineering make it suitable for continuous industrial operation in demanding automation setups.

Functions

The main function of the Siemens 6ES7341-1AH02-0AE0 is to provide a standardized RS-232C serial communication interface for PLC-based systems. It enables the exchange of data between the S7-300 controller and external serial devices.

Key functions include:

Serial communication via RS-232C (V.24)
Isolated interface for electrical protection
Data transmission between PLC and peripheral devices
Support for configurable baud rates from 0.3 to 115.2 kbit/s
Integration into Siemens S7-300 backplane system

Features

Single isolated RS-232C (V.24) serial communication interface
Supports wide baud rate range from 0.3 kbit/s to 115.2 kbit/s for flexible device compatibility
Maximum cable length up to 15 m, suitable for typical industrial serial connections
Electrical isolation on the interface side to enhance signal stability and protect PLC hardware
Standard 9-pin D-sub connector for easy and widely compatible wiring integration
Powered by 24 V DC with controlled current consumption from supply and backplane bus
Low power loss design (typical 1.6 W, maximum 2.4 W) for efficient operation in continuous use
Designed for Siemens S7-300 automation system integration with stable backplane communication
Industrial-grade construction for reliable performance in electrically noisy environments
Compact and robust module design suitable for control cabinet installation in automation systems

Advantage

Compared with generic RS-232 interface modules, the Siemens 6ES7341-1AH02-0AE0 offers several key advantages:

1. Native Siemens S7-300 Integration
Unlike third-party modules, the Siemens 6ES7341-1AH02-0AE0 integrates directly into S7-300 systems, reducing configuration effort and improving compatibility.

2. Electrical Isolation for System Safety
The isolated interface significantly reduces the risk of ground loops and electrical noise interference compared to non-isolated RS-232 modules.

3. Wider Industrial Compatibility
Supports a broad range of baud rates (0.3–115.2 kbit/s), allowing flexible communication with diverse industrial devices.

4. Reliable Industrial Communication
Compared with low-cost serial converters, the Siemens 6ES7341-1AH02-0AE0 provides more stable signal performance in electrically noisy environments.

5. Optimized Power Efficiency
With a typical power loss of 1.6 W, it offers better energy efficiency than many generic PLC communication modules.

6. Robust Mechanical and Electrical Design
Built with Siemens industrial standards, it ensures longer service life and higher durability compared to commercial-grade RS-232 adapters.

FAQ

Q1: What is the purpose of Siemens 6ES7341-1AH02-0AE0?
A: The Siemens 6ES7341-1AH02-0AE0 is used to provide an RS-232C serial communication interface for S7-300 PLC systems, enabling communication with external devices such as printers and barcode scanners.

Q2: Does 6ES7341-1AH02-0AE0 support electrical isolation?
A: Yes, the Siemens 6ES7341-1AH02-0AE0 features an isolated RS-232C interface to improve signal stability and protect the PLC from electrical interference.

Q3: What is the maximum transmission speed of 6ES7341-1AH02-0AE0?
A: The Siemens 6ES7341-1AH02-0AE0 supports a transmission rate ranging from 0.3 kbit/s up to 115.2 kbit/s.

Q4: What is the maximum cable length for 6ES7341-1AH02-0AE0?
A: The Siemens 6ES7341-1AH02-0AE0 supports a maximum cable length of up to 15 meters for RS-232 communication.

Q5: What devices can be connected to 6ES7341-1AH02-0AE0?
A: The Siemens 6ES7341-1AH02-0AE0 can connect to RS-232 compatible industrial devices such as printers, barcode scanners, HMIs, and other serial equipment.
