Siemens 6ES7341-1BH02-0AE0 SIMATIC S7-300 CP341 Communication Processor

Siemens 6ES7341-1BH02-0AE0 SIMATIC S7-300 CP341 Communication Processor

Product Name: SIMATIC S7-300 CP341 Communication Processor

Brand Name: Siemens

Model Number: 6ES7341-1BH02-0AE0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7341 1bh02 0ae0 simatic s7 300 cp341 communication processor-1

Overview
Product Parameters
Commercial Terms
Contact Us
Why Choose US
Major Business
Product Feature
FAQ
Recommended Products

Overview

The Siemens 6ES7341-1BH02-0AE0 SIMATIC S7-300 CP341 Communication Processor is a serial communication processor designed for the SIMATIC S7-300 PLC platform. Equipped with a galvanically isolated 20 mA current loop (TTY) interface, it enables reliable serial communication with printers and industrial devices using 3964(R), ASCII, and RK512 protocols. Supporting transmission rates from 0.3 to 19.2 kbit/s and cable lengths of up to 1,000 meters, the module provides dependable data exchange for industrial automation and process control applications.

Product Parameters

Product Name	Siemens 6ES7341-1BH02-0AE0 SIMATIC S7-300 CP341 Communication Processor
Manufacturer	Siemens
Product Type	SIMATIC S7-300 CP341 Communication Processor
Part Number	6ES7341-1BH02-0AE0
Place of shipment	Xiamen, China
Country of origin	Germany
Communication Interface	20 mA Current Loop (TTY)
Number of Interfaces	1 (Galvanically Isolated)
Rated Supply Voltage	24 V DC
Current Consumption (L+)	Max. 100 mA
Backplane Bus Current	Max. 70 mA @ 5 V DC
Typical Power Dissipation	1.6 W
Maximum Power Dissipation	2.4 W
Transmission Rate	0.3 to 19.2 kbit/s
Maximum Cable Length	1,000 m
Connector Type	9-pin Sub-D Socket
Supported Devices	Serial Printers
Supported Protocols	3964(R), ASCII, RK512
Maximum Telegram Length	4,096 Bytes
Maximum Protocol Speed	19.2 kbit/s (3964(R), ASCII, RK512, Printer Driver)
Operating Temperature	0 to +60 °C
Storage Temperature	-40 to +70 °C
Function Block (FB) Size	Max. 6,100 Bytes
Power Connection	3 Screw-Type Terminals (L+, M, GND)

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales:	Email:	Whatsapp:
Jim Pei	[email protected]	+86 18020776782

Why Choose US

✔ Genuine Industrial Automation Products
✔ Strict Quality Inspection Before Shipment
✔ Competitive Prices & Flexible Quotations
✔ Large Inventory with Fast Global Shipping
✔ 12-Month Warranty on Eligible Products
✔ Professional Technical & After-Sales Support
✔ Inquiry Response Within 1 Hour
✔ Secure Packaging for International Shipping
✔ Trusted Supplier for PLC, DCS, HMI, and Industrial Control Systems

Major Business

ABB: Industrial robot parts of DSQC series,Bailey INFI90, DCS
Honeywell: 51/MU/MC/TC/CC ...
Triconex: 3008/3511/3625/3664/3721/3700A..
Bently Nevada: 3500/3300/330180-Cable..
Foxboro: FBM203/204/217/231, FCP240/270
Woodward: SPC valve position controller, PEAK15 digital controller
Siemens: 6DD/6DP/6ES5/6DR/6GK Series
Westinghouse Series: 1C/5X ...
General electric: IC693/IC697/IC695/DS200..
Schneider: 140 Series

Product Feature

20 mA Current Loop Interface
Features one galvanically isolated TTY interface for reliable long-distance serial communication.
Multiple Serial Protocols
Supports 3964(R), ASCII, RK512, and printer communication for broad industrial compatibility.
Long Communication Distance
Enables serial communication over cable lengths of up to 1,000 meters.
Flexible Transmission Speeds
Supports configurable data rates from 0.3 kbit/s to 19.2 kbit/s to match application requirements.
Large Telegram Capacity
Handles telegram lengths of up to 4,096 bytes for efficient data transfer.
Low Power Consumption
Operates with a maximum current consumption of 100 mA at 24 V DC and low power dissipation.
Industrial-Grade Reliability
Designed for continuous operation in temperatures from 0°C to +60°C with galvanic isolation for improved noise immunity.
Optimized for SIMATIC S7-300
Integrates seamlessly with SIMATIC S7-300 PLC systems for dependable serial communication applications.

FAQ

---What is the 6ES7341-1BH02-0AE0 used for?
6ES7341-1BH02-0AE0 is used to provide serial communication between SIMATIC S7-300 controllers and industrial devices through a 20 mA current loop interface.

---What is the maximum cable length supported by the 6ES7341-1BH02-0AE0?
6ES7341-1BH02-0AE0 supports communication distances of up to 1,000 meters.

---What type of connector does the 6ES7341-1BH02-0AE0 use?
6ES7341-1BH02-0AE0 uses a 9-pin Sub-D socket for its communication interface.

---Which devices can be connected to the 6ES7341-1BH02-0AE0?
6ES7341-1BH02-0AE0 supports communication with compatible serial devices, including industrial equipment and serial printers.

---What is the operating temperature range of the 6ES7341-1BH02-0AE0?
6ES7341-1BH02-0AE0 operates in ambient temperatures from 0°C to +60°C.

---What are the main benefits of the 6ES7341-1BH02-0AE0?
6ES7341-1BH02-0AE0 provides reliable serial communication, long-distance connectivity, support for multiple industrial protocols, galvanic isolation, low power consumption, and seamless integration with SIMATIC S7-300 automation systems.
