Product Name: FM350-2 High Speed Counter Module
Brand Name: Siemens
Model Number: 6ES7350-2AH00-0AE0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7350-2AH00-0AE0 FM350-2 High Speed Counter Module |
| Manufacturer | Siemens |
| Product Type | FM350-2 High Speed Counter Module |
| Part Number | 6ES7350-2AH00-0AE0 |
| Weight | 0.42 kg |
| Estimated shipping dimensions | 8x11.7x12.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Rated value (DC) | 24 V |
| permissible range, lower limit (DC) | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V |
| Rated value | 200 mA |
| Power loss, typ. | 10 W |
| Number of digital inputs | 8 |
| Number of NAMUR inputs | 8 |
| Functions | 1 each for gate start/ gate stop |
| Input voltage for signal "0" | -3 to +5V |
| Input voltage for signal "1" | 11 to 30.2 V |
| with resistive load, max. | 500 Hz |
| with inductive load, max. | 0.5 Hz |
| Counter input 24 V Number | 8; 32 bit or ±31 bit |
| Input delay, max. | 50 µs |
The Siemens 6ES7350-2AH00-0AE0 FM350-2 High Speed Counter Module is a specialized signal processing module designed for high-speed counting applications in SIMATIC S7-300 automation systems. It enables precise acquisition and processing of fast pulse signals from sensors, encoders, and measuring devices, making it suitable for motion control, production counting, and position detection tasks.
The module is engineered to handle high-frequency digital inputs with exceptional accuracy and responsiveness. With support for up to 8 digital inputs and 8 NAMUR inputs, it provides flexible connectivity for industrial sensing applications. Its robust design ensures reliable operation in demanding industrial environments where fast signal acquisition and precise timing are critical.
High-Speed Pulse Counting
Processes fast pulse signals from sensors and encoders for accurate counting and measurement applications.
Multi-Channel Input Handling
Supports up to 8 digital inputs and 8 NAMUR inputs for flexible industrial signal acquisition.
Gate Control Operation
Provides gate start and gate stop functions for precise control of counting intervals.
Signal Processing & Conversion
Converts incoming digital signals into processed count values for PLC use.
Fast Input Response
Handles high-speed signals with input delay up to 50 µs for real-time accuracy.
Counter Value Processing
Supports 32-bit or ±31-bit counter resolution for high-precision measurement tasks.
Load Compatibility
Operates with resistive loads up to 500 Hz and inductive loads up to 0.5 Hz.
System Integration
Integrates into SIMATIC S7-300 automation systems for motion control and industrial counting applications.
Compared to similar high-speed counter modules, this 6ES7350-2AH00-0AE0 provides superior accuracy, faster response, and more flexible input handling, making it highly suitable for demanding motion control and precision counting applications.
The 6ES7350-2AH00-0AE0 FM350-2 High Speed Counter Module delivers precise and reliable high-frequency signal processing for industrial automation systems. Its ability to handle fast pulse inputs with a maximum delay of 50 µs ensures accurate real-time counting even in dynamic production environments. The module supports both digital and NAMUR inputs, enabling broad compatibility with industrial sensors and measurement devices.
Operating at a typical power loss of 10 W, the module maintains efficient energy usage while providing high-performance signal processing. Its 32-bit counter resolution ensures high measurement accuracy, making it ideal for applications requiring precise speed, position, or event counting.
