SIEMENS 6ES7417-4HT14-0AB0 CPU 417H Central processing unit Ready For Ship

SIEMENS 6ES7417-4HT14-0AB0 CPU 417H Central processing unit Ready For Ship

Product Name:CPU 417H Central processing unit

Brand Name:Siemens

Model Number:6ES7417-4HT14-0AB0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7417 4ht14 0ab0 cpu 417h central processing unit ready for ship-1

Overview
Get your discount today
Specifications
Description
Applications
Technical Data Summary
Environmental Strength
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7417-4HT14-0AB0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Get your discount today

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6ES7417-4HT14-0AB0
Product Name	SIMATIC S7-400H CPU 417H
Manufacturer	Siemens
Product Type	Redundant PLC Central Processing Unit
Series	SIMATIC S7-400H
Firmware Version	V4.5
Work Memory	30 MB (15 MB Program / 15 MB Data)
Communication Interfaces	1 MPI/PROFIBUS DP, 1 PROFIBUS DP, 2 Synchronization Interfaces
PROFIBUS Speed	Up to 12 Mbit/s
DP Master Capacity	Up to 125 DP Slaves
Digital I/O Capacity	131,072 Inputs / 131,072 Outputs
Analog I/O Capacity	8,192 Inputs / 8,192 Outputs
Programming Software	STEP 7 V5.3 SP2 or later
Supply Method	Powered via S7-400 Backplane Bus
Typical Power Consumption	6.5 W
Dimensions	50 × 290 × 219 mm
Weight	Approx. 995 g

Description

The 6ES7417-4HT14-0AB0 is a high-performance fault-tolerant CPU from the Siemens SIMATIC S7-400H automation platform, engineered for continuous industrial operation where system availability is critical. Featuring 30 MB integrated memory, dual PROFIBUS DP interfaces, and dedicated synchronization ports, it delivers reliable processing for complex control architectures.

Designed for redundant automation systems, the 6ES7417-4HT14-0AB0 supports seamless CPU synchronization, fast instruction execution, and extensive communication capabilities. It is fully compatible with SIMATIC S7-400H, STEP 7, and distributed PROFIBUS networks, making it suitable for large-scale process control applications.

With excellent processing speed, high I/O capacity, and dependable redundancy functions, the 6ES7417-4HT14-0AB0 helps improve plant uptime, simplify maintenance, and ensure stable operation in industries such as power generation, oil & gas, chemical processing, metallurgy, and critical manufacturing environments.

Applications

Power plants: Used for turbine control, generator redundancy, plant-wide process automation, and critical safety monitoring.
Oil & gas facilities: Supports redundant control systems, compressor stations, pipeline automation, and emergency shutdown processes.
Chemical plants: Integrates continuous process control, distributed I/O management, and hazardous production monitoring.
Steel mills: Performs reliable automation for rolling mills, blast furnaces, material handling systems, and high-temperature production lines.
Water treatment plants: Controls pumping stations, filtration systems, dosing equipment, and SCADA communication networks.
Pharmaceutical manufacturing: Provides stable batch process control and production line synchronization.
Large manufacturing plants: Coordinates automated production lines, robotic cells, conveyors, and centralized PLC control systems.

Technical Data Summary

CPU Architecture: Siemens SIMATIC S7-400H redundant PLC processor designed for high-availability industrial automation.
Memory Capacity: 30 MB integrated work memory divided into program and data storage for large-scale applications.
Communication Performance: Dual PROFIBUS DP master interfaces provide reliable high-speed fieldbus communication up to 12 Mbit/s.
Redundancy Capability: Supports optical synchronization modules for fault-tolerant CPU operation with seamless switching.
Processing Speed: High-speed instruction execution enables deterministic control of complex industrial processes.
System Compatibility: Compatible with STEP 7 engineering software and distributed SIMATIC S7 automation platforms.
Expandability: Supports numerous expansion racks, communication processors, and distributed I/O devices for scalable system design.

Environmental Strength

Operates reliably in demanding industrial environments requiring continuous system availability.
Redundant architecture minimizes unexpected production downtime.
Optical synchronization improves communication reliability between redundant CPUs.
Industrial-grade construction ensures long-term operational stability.
Low power consumption helps reduce cabinet heat generation.
Built-in diagnostics simplify preventive maintenance and fault identification.
Suitable for power generation, petrochemical, metallurgy, transportation, and other mission-critical automation industries.
Designed for long service life in applications requiring maximum system reliability and process safety.

FAQ

Q1: What is the 6ES7417-4HT14-0AB0 used for?
A1: It is a redundant SIMATIC S7-400H CPU designed for high-availability industrial automation and critical process control applications.

Q2: Does the 6ES7417-4HT14-0AB0 support redundant operation?
A2: Yes. It is specifically designed for S7-400H redundant systems using dedicated optical synchronization modules.

Q3: Which engineering software is compatible with the 6ES7417-4HT14-0AB0?
A3: It supports Siemens STEP 7 V5.3 SP2 or later with the required hardware updates.

Q4: How much memory does the 6ES7417-4HT14-0AB0 provide?
A4: The CPU includes 30 MB of integrated work memory, divided into 15 MB for program storage and 15 MB for data storage.

Q5: Which industries commonly use the 6ES7417-4HT14-0AB0?
A5: It is widely used in power generation, oil & gas, chemical processing, water treatment, metallurgy, and other industrial facilities requiring continuous and fault-tolerant automation.
