CPU 1511-1 PN with separate program and data work memory, PROFINET IRT and an integrated two-port switch.
Sales |
Jim Pei |
Email |
|
Phone/Whatsapp |
|
Model Number
|
6ES7511-1AL03-0AB0
|
|
Program work memory
|
300 kbyte
|
|
Data work memory
|
1.5 Mbyte
|
|
Rated supply voltage
|
24 V DC
|
|
Permitted supply range
|
19.2–28.8 V DC
|
|
Rated current consumption
|
0.56 A
|
|
Maximum current consumption
|
0.9 A
|
|
Inrush current
|
1.15 A, rated value
|
|
Inrush I²t
|
0.5 A²·s
|
|
Voltage failure buffering
|
5 ms
|
|
Backplane infeed power
|
10 W
|
|
Balanced backplane power consumption
|
5.5 W
|
|
Typical power loss
|
3.4 W
|
|
SIMATIC Memory Card slots
|
1
|
|
Maximum plug-in load memory
|
32 Gbyte
|
|
Bit instruction time, typical
|
6 ns
|
|
Word instruction time, typical
|
7 ns
|
|
Fixed-point operation time, typical
|
9 ns
|
|
Floating-point operation time, typical
|
37 ns
|
|
Total blocks and UDT elements
|
4,000
|
|
Maximum FB size
|
300 kbyte
|
|
Maximum FC size
|
300 kbyte
|
|
Maximum DB size
|
1.5 Mbyte; 64 kbyte for absolute addressing
|
|
Retentive data area, maximum
|
216 kbyte, total
|
|
Flag memory, maximum
|
16 kbyte
|
|
S7 counters
|
2,048
|
|
S7 timers
|
2,048
|
|
Input address area
|
32 kbyte
|
|
Output address area
|
32 kbyte
|
|
Maximum modules per rack
|
32, CPU plus 31 modules
|
|
Integrated PROFINET switch ports
|
2
|
|
PROFINET interface
|
IRT
|
|
Cyclic interrupt OBs
|
20, minimum OB 3x cycle 250 µs
|
|
Minimum Order Quantity
|
1 Piece
|
|
Price
|
Contact for Jim
|
|
Packaging Details
|
Original new Factory Sealed
|
|
Delivery Time
|
3–7 Days
|
|
Payment Terms
|
T/T
|
|
Shipping Method
|
DHL / FedEx / UPS / TNT
|
|
Supply Ability
|
In stock
|
Siemens 6ES7511-1AL03-0AB0 is the SIMATIC S7-1500 CPU 1511-1 PN central processing unit. Separate work-memory areas hold the user program and data. Its integrated PROFINET interface includes a two-port switch and supports IRT communication. Fast instruction processing supports the execution of machine control logic. A SIMATIC Memory Card is required for the configured system.
The 6ES7511-1AL03-0AB0 forms the controller core of a suitable S7-1500 automation station. Distributed and local I/O can be integrated within the documented configuration limits. System diagnostics and engineering functions support commissioning and maintenance. Select the firmware and TIA Portal version together with the existing project. Replacement planning should include the memory card, project backup and connected network configuration.
Executes the user program as the central CPU of an S7-1500 station.
Connects the controller with compatible distributed I/O through PROFINET.
Supports documented isochronous operation within the configured system limits.
Project engineering — Use the engineering version appropriate to the installed firmware.
Diagnostic access — Controller diagnostics assist commissioning and system maintenance.
Program storage planning — Provide the required SIMATIC Memory Card and verified project backup.
The product specification requires a SIMATIC Memory Card.
It depends on firmware; the supplied datasheet lists V21 for FW V4.1 and V18 for FW V3.0.
No. Match the complete article number and review project migration before replacement.
Request the offered-unit label photo and available condition or inspection details.
We arrange immediate dispatch once payment is received.
Send the firmware requirement, existing project version and whether a memory card is needed.
