Siemens 6ES7512-1CK00-0AB0 SIMATIC S7-1500 CPU 1512C-1 PN Compact Controller

Siemens 6ES7512-1CK00-0AB0 SIMATIC S7-1500 CPU 1512C-1 PN Compact Controller

Product Name: SIMATIC S7-1500 CPU 1512C-1 PN Compact Controller

Brand Name: Siemens

Model Number: 6ES7512-1CK00-0AB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp: +86 18020776782

Email: [email protected]

Appurtenance:

siemens 6es7512 1ck00 0ab0 simatic s7 1500 cpu 1512c 1 pn compact controller-1

Overview
Specifications
Description
Commercial Term
Contact info
FAQ
Other Products
Recommended Products

Keep controller, onboard I/O and project archive aligned

The CPU 1512C-1 PN combines an S7-1500 controller with integrated digital and analog I/O, high-speed functions and a PROFINET interface.

Before you order: Before exchange, compare the exact order number, firmware, TIA Portal project, memory card and field wiring. Do not infer that a later order revision is drop-in compatible.

Specifications

Product family

SIMATIC S7-1500

Controller

CPU 1512C-1 PN

Program memory

250 KB

Data memory

1 MB

Digital I/O

32 inputs / 32 outputs

Analog I/O

5 inputs / 2 outputs

High-speed functions

6 counters and 4 PTO/PWM/frequency outputs

Network

PROFINET IRT, two-port switch

Memory card

SIMATIC memory card required

Description

This compact CPU integrates control and I/O in one S7-1500 unit. Siemens documents 32 digital inputs, 32 digital outputs, five analog inputs, two analog outputs and PROFINET IRT with a two-port switch.

For service, open a verified project archive and map the front connectors before removing the installed CPU. Confirm the SIMATIC memory card and device configuration, then commission each I/O group and network connection against the approved project.

Configuration & Programming

Retain the TIA Portal project, firmware information and SIMATIC memory card. Check the exact hardware object used in the project before downloading.

Installation & Integration

Label front-connector wiring and distinguish CPU supply from load supply. Recheck the onboard analog and high-speed I/O assignments after replacement.

Commercial Term

Quotation

Current price and availability

Payment

T/T or agreed terms

Lead time

Confirmed with quotation

Shipping

DHL, FedEx, UPS or agreed freight

Warranty

12 months

Contact info

CONTACT

Jim Pei

[email protected]

+86 180 2077 6782

FAQ

How should I verify 6ES7512-1CK00-0AB0 against an existing TIA Portal project?

Compare the complete order number and firmware with the hardware configuration. Check the memory card, onboard I/O mapping and PROFINET device name before scheduling the exchange.

What should be saved before replacing 6ES7512-1CK00-0AB0?

Archive and open the approved TIA Portal project, record online diagnostics and firmware, and document card contents, connector positions, IP settings and I/O terminal wiring.

Why might 6ES7512-1CK00-0AB0 start but show I/O faults after an exchange?

Check the seated front connectors, 24 V CPU and load supplies, channel wiring and project configuration. Compare diagnostic buffer entries with the original installation.

What should I check if PROFINET devices do not reconnect to 6ES7512-1CK00-0AB0?

Verify the configured device name, IP address, port connections and controller project. Use the CPU and device diagnostics to separate a topology fault from a configuration mismatch.

Can I move a memory card from another controller into 6ES7512-1CK00-0AB0?

Only after confirming its contents and compatibility with the approved project and CPU firmware. Preserve a verified backup and follow the site commissioning procedure.

How should purchasing specify 6ES7512-1CK00-0AB0 for a service spare?

Send the full order number, installed hardware and firmware, TIA Portal version, memory-card requirement and photos of the connector and nameplate.
