Product Name: SIMATIC S7-1500 DQ32x24 VDC/0.5A BA Digital Output Module
Brand Name: Siemens
Model Number: 6ES7522-1BL10-0AA0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
Phone/Whatsapp |
|
Jim Pei |
| Product Name | Siemens 6ES7522-1BL10-0AA0 SIMATIC S7-1500 DQ32x24 VDC/0.5A BA Digital Output Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC S7-1500 DQ32x24 VDC/0.5A BA Digital Output Module |
| Part Number | 6ES7522-1BL10-0AA0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Product Family | SIMATIC S7-1500 |
| Product Type | Digital Output Module |
| Module Designation | DQ32x24 V DC/0.5A BA |
| Hardware Functional Status | FS01 |
| Firmware Version | V1.0.0 |
| Firmware Update | Yes |
| Number of Digital Outputs | 32 |
| Digital Output Type | Transistor, Current-Sourcing |
| Channel Grouping | 4 Groups of 8 Channels |
| Rated Output Voltage | 24 VDC |
| Rated Output Current per Channel | 0.5 A |
| Maximum Current per Group | 4 A |
| Maximum Current per Module | 16 A |
| Rated Supply Voltage | 24 VDC |
| Permissible Supply Voltage Range | 20.4–28.8 VDC |
| Reverse Polarity Protection | Yes |
| Maximum Current Consumption | 60 mA |
| Power from Backplane Bus | 1.15 W |
| Typical Power Loss | 3.8 W |
| Short-Circuit Protection | Yes |
| Typical Short-Circuit Response Threshold | 1 A |
| Maximum Resistive Load per Output | 0.5 A |
| Maximum Lamp Load | 5 W |
| Load Resistance Range | 48 Ω–12 kΩ |
| Signal “1” Minimum Output Voltage | L+ (-0.8 V) |
| Signal “0” Maximum Residual Current | 0.5 mA |
| Output Delay 0 → 1 | 100 µs max. |
| Output Delay 1 → 0 | 500 µs max. |
| Maximum Switching Frequency – Resistive Load | 100 Hz |
| Maximum Switching Frequency – Inductive Load | 0.5 Hz, IEC 60947-5-1 DC-13 |
| Maximum Switching Frequency – Lamp Load | 10 Hz |
| Parallel Outputs for Logic Links | Yes |
| Redundant Control of a Load | Yes |
| Maximum Shielded Cable Length | 1,000 m |
| Maximum Unshielded Cable Length | 600 m |
| Diagnostics Function | No |
| Diagnostic Alarm | No |
| RUN LED | Yes, Green |
| ERROR LED | Yes, Red |
| PWR LED | Yes, Green |
| Channel Status Display | Yes, Green LED |
| Channel Isolation | Groups of 8 |
| Isolation from Backplane Bus | Yes |
| Isolation Test Voltage | 707 VDC |
| Safety Functions | No |
| Maximum Installation Altitude | 5,000 m |
| Included Accessory | 40-Pole Push-In Front Connector |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7522-1BL10-0AA0 is a SIMATIC S7-1500 DQ32x24 VDC/0.5A BA Digital Output Module designed for high-density discrete output control in industrial automation systems. It provides 32 current-sourcing transistor outputs for controlling actuators, relays, contactors, indicators, valves, and other 24 VDC field devices. With fast switching, short-circuit protection, channel isolation, and direct S7-1500 integration, the 6ES7522-1BL10-0AA0 is well suited for machine automation, manufacturing lines, process control, material handling, and PLC I/O expansion applications.
