Siemens 6GK1415-2AA10 SIMATIC NET DP/AS-Interface Link 20 E Gateway
Siemens 6GK1415-2AA10 SIMATIC NET DP/AS-Interface Link 20 E Gateway
Siemens 6GK1415-2AA10 SIMATIC NET DP/AS-Interface Link 20 E Gateway
Siemens 6GK1415-2AA10 SIMATIC NET DP/AS-Interface Link 20 E Gateway
Siemens 6GK1415-2AA10 SIMATIC NET DP/AS-Interface Link 20 E Gateway
Siemens 6GK1415-2AA10 SIMATIC NET DP/AS-Interface Link 20 E Gateway
Siemens 6GK1415-2AA10 SIMATIC NET DP/AS-Interface Link 20 E Gateway
Siemens 6GK1415-2AA10 SIMATIC NET DP/AS-Interface Link 20 E Gateway
Siemens 6GK1415-2AA10 SIMATIC NET DP/AS-Interface Link 20 E Gateway
Siemens 6GK1415-2AA10 SIMATIC NET DP/AS-Interface Link 20 E Gateway

Siemens 6GK1415-2AA10 SIMATIC NET DP/AS-Interface Link 20 E Gateway

SIEMENS / SIMATIC NET
Product Name: SIMATIC NET DP/AS-Interface Link 20 E Gateway
Brand Name:
Siemens
Model Number:
6GK1415-2AA10
Place of Origin:
Germany
Warranty:
12 Months
Appurtenance:
siemens 6gk1415 2aa10 simatic net dp as interface link 20 e gateway-1
Inquiry
  • Overview
  • Specifications
  • Contact info
  • Description
  • Function
  • FAQ
  • Our Company History
  • Why Choose Us
  • Other Products
  • Recommended Products

Commercial Terms

Minimum Order Quantity
1 Piece
Price
Contact for Jim
Packaging Details
Original new Factory Sealed
Delivery Time
3–7 Days
Payment Terms
T/T
Shipping Method
DHL / FedEx / UPS / TNT
Supply Ability
In stock

Specifications

Model Number
6GK1415-2AA10
AS-Interface specification
V3.0
AS-i master profile
M4
AS-Interface connections
1
RS485 connections
1
Maximum AS-i slaves
62
Maximum AS-i inputs
496
Maximum AS-i outputs
496
AS-i cycle with 31 slaves
5 ms
AS-i cycle with 62 slaves
10 ms
Supply source
AS-Interface cable
Current at 30 V
200 mA maximum
Power loss
4.5 W
Rated insulation voltage
500 V
AS-i connection
Screw terminals
Horizontal-rail operating temperature
0–60 °C
Vertical-rail operating temperature
0–45 °C
Transport temperature
-40 to +70 °C
Storage temperature
-40 to +70 °C
Maximum relative humidity at 25 °C
95%
Maximum installation altitude
2000 m above sea level
Protection rating
IP20
Mounting rail
35 mm DIN rail
Status LEDs
PWR, APF, CER, AUP, CM, BF, SF
Hazardous gas marking
II 3 G Ex ec IIC T4 Gc
Digital data access
Process image / peripheral addresses
Analog data access
Data record transfer
Redundancy arrangement
Supported with Y-Link
AS-i Power24V
Not supported
Safety protocols
ASIsafe and PROFIsafe not supported
Galvanic isolation
Provided

Contact info

Sales
Jim Pei
Phone/Whatsapp

Description

01

Siemens 6GK1415-2AA10 is the SIMATIC NET DP/AS-Interface Link 20 E gateway. It connects an AS-Interface network to PROFIBUS DP. The gateway complies with AS-Interface specification V3.0 and supports the M4 master profile. Up to 62 AS-i slaves can be connected. The device is supplied through the AS-i cable.

02

Digital I/O is accessed through process-image or peripheral addressing. Analog I/O is transferred through data records. Configuration is available through the device pushbutton, STEP 7, GSD or the command interface. Status LEDs assist local commissioning and fault checks. This order number is not intended for safety-related control functions.

Function

A
Fieldbus gateway
The link transfers data between the PROFIBUS DP controller and the connected AS-i devices.
B
Digital and analog access
Digital process data and analog records use their respective data-access paths in the engineering configuration.
C
Commissioning choices
The device supports pushbutton configuration and the listed engineering interfaces for parameter assignment.

FAQ

Q1Does 6GK1415-2AA10 need a separate auxiliary supply?
Its supply is taken from the AS-Interface cable. Verify the AS-i power arrangement before installation.
Q2How are analog values retrieved through 6GK1415-2AA10?
Analog I/O uses data record transfer, rather than the digital process-image access path.
Q3Can 6GK1415-2AA10 be used as an ASIsafe controller?
No. ASIsafe, PROFIsafe and safety-related operation are not supported.
Q4Can 6GK1415-2AA10 be paired with a Y-Link?
The data sheet specifies redundancy capability in connection with a Y-Link. Check the system configuration.
Q5What evidence can I receive for the supplied 6GK1415-2AA10?
Actual-item photos and condition confirmation are available, with testing before delivery and the agreed warranty.
Q6Is dispatch delayed after payment for 6GK1415-2AA10?
Available stock is sent immediately after payment is received; we provide shipment tracking.
