Siemens 6GK5213-3BF00-2TB2 SCALANCE XB213-3LD Switch

Siemens 6GK5213-3BF00-2TB2 SCALANCE XB213-3LD Switch

Product Name: SCALANCE XB213-3LD Managed Ethernet Switch

Brand Name: Siemens

Model Number: 6GK5213-3BF00-2TB2

Place of Origin: Germany

Warranty: 12 Months

Whatsapp: +86 18020776782

Email: [email protected]

Overview
Description
Specifications
Commercial Term
Contact info
FAQ
Other Products
Recommended Products

Plan the copper-to-single-mode optical boundary as one network

A managed Layer 2 industrial switch with 13 RJ45 10/100 Mbps ports and three single-mode SC optical ports.

Verify first: This order variant is supplied with EtherNet/IP as the default. Review the plant protocol, fiber path, configuration and firmware before integration.

Description

The Siemens XB213-3LD combines high-density copper access with long-distance single-mode optical connections. Its official listing identifies a console port, diagnostic LEDs, redundant supply, DIN-rail mounting and a 0 to +60 °C operating range.

Treat a replacement as a managed-network change: document the port map, save the running configuration and verify fiber type and connector orientation. The default EtherNet/IP setting must be checked against the actual engineering project before commissioning.

Operating Environment

Siemens states a 0 to +60 °C temperature range and DIN-rail installation. Confirm enclosure ventilation and the actual site conditions before placing the switch in service.

System Integration

Record the console access, approved port configuration, IP settings and protocol selection. Check the three single-mode SC links end-to-end rather than assuming any optical module is interchangeable.

Specifications

Product family

SCALANCE XB-200 managed

Copper interfaces

13 × RJ45, 10/100 Mbps

Optical interfaces

3 × single-mode SC

Management

Layer 2 managed

Service access

Console port and diagnostic LEDs

Power

Redundant supply input

Operating temperature

0 to +60 °C

Mounting

DIN rail

Factory default

EtherNet/IP

Certification

IEC 62443-4-2 per Siemens listing

Commercial Term

Quotation

Current price and availability

Payment

T/T or agreed terms

Lead time

Confirmed with quotation

Shipping

DHL, FedEx, UPS or agreed freight

Warranty

12 months

Contact info

CONTACT

Jim Pei

[email protected]

+86 180 2077 6782

FAQ

How can I verify 6GK5213-3BF00-2TB2 for an existing single-mode network?

Compare the complete order number, SC fiber paths, partner optics, 13 copper destinations and current configuration. Confirm the required protocol and firmware with the engineering project.

What should be saved before replacing 6GK5213-3BF00-2TB2?

Export the running switch configuration, note IP and management access, label every port and record fiber routes, redundant supply wiring and the protocol setting.

Why might a fiber link remain inactive after installing 6GK5213-3BF00-2TB2?

Verify single-mode fiber and SC connector seating, the far-end device and Tx/Rx routing. Then inspect LEDs and port diagnostics before changing managed settings.

What should I check if 6GK5213-3BF00-2TB2 has link but devices do not exchange data?

Review the factory/default protocol against the intended plant configuration, then compare IP settings, VLANs, access rules and controller diagnostics with the approved backup.

How do I investigate recurring alarms from 6GK5213-3BF00-2TB2 in a cabinet?

Check the 0 to +60 °C ambient range, ventilation, both supply feeds, error logs and affected ports. Correlate symptoms with heat, power events or fiber movement.

What should procurement include when requesting 6GK5213-3BF00-2TB2?

Send the exact order number, installed firmware and configuration constraints, fiber medium, protocol requirement, required condition, accessories and delivery destination.
