Product Name: SCALANCE XR324-12M Managed IE Switch
Brand Name: Siemens
Model Number: 6GK5324-0GG00-1AR2
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
Fast response for industrial automation sourcing
| SalesJim Pei | Email[email protected] | Phone/Whatsapp+86 18020776782 |
| PARAMETER | OFFICIAL VALUE |
|---|---|
| Model Number | 6GK5324-0GG00-1AR2 |
| Transfer rate / 1 | 10 Mbit/s |
| Transfer rate / 2 | 100 Mbit/s |
| Transfer rate / 3 | 1000 Mbit/s |
| Operating voltage / of signaling contacts / at DC / rated value | 24 V |
| Operating current / of signaling contacts / at DC / maximum | 0.1 A |
| Consumed current / maximum | 1.8 A |
| during transport | 40 … +70 °C |
| Protection class IP | IP20 |
| Product-type designation | SCALANCE XR324-12M |
| for signaling contact | 2-pole terminal block |
| external | 24 V |
| at 24 V / for DC | 44 W |
| during operating | 40 … +70 °C |
| during storage | 40 … +70 °C |
| at 25 °C / without condensation / during operating / maximum | 95 % |
| Design | 19" rack |
| Type of mounting | When used in shipbuilding, the device must be secured in the 19" |
| from FM | FM3611: Class 1, Division 2, Group A, B, C, D / T4, Class 1, Zone 2, |
| for hazardous zone | EN 60079-0 : 2006, EN 60079-15: 2005, II 3 G Ex nA II T4 KEMA 07 |
| for safety / of CSA and UL | UL 60950-1, CSA C22.2 No. 60950-1-03 |
| for hazardous area / of CSA and UL | UL 1604 and UL 2279-15 (Hazardous Location), CSA C22.2 No. 213 |
| for emitted interference | EN 61000-6-4:2007 (Class A) |
| letzte Änderung: | May 28, 2012 |
| Number of electrical/optical connections / for network components or | 24 |
| for power supply | 1 |
| for redundant power supply | 1 |
| for operator console | 1 |
| for alarm contact | 1 |
| for media module | 12 |
| Product component / fusing at power supply input | Yes |
| Cascading in the case of a redundant ring / at reconfiguration time of | 50 |
| MIB support | Yes |
| Port mirroring | Yes |
| Port diagnostics | Yes |
|
01
6GK5324-0GG00-1AR2 is suitable for industrial rack backbones, modular fiber or copper Ethernet networks, and high-availability control-system communication. |
02
It can also support PROFINET IO, ring redundancy, VLAN segmentation, traffic monitoring, and plant-wide managed networking. |
|
