Siemens 6GK5528-0AR00-2AR2 SCALANCE XR528-6M Managed Layer 3 Industrial Ethernet Switch

Siemens 6GK5528-0AR00-2AR2 SCALANCE XR528-6M Managed Layer 3 Industrial Ethernet Switch

Product Name: SCALANCE XR528-6M Managed Layer 3 Industrial Ethernet Switch
Brand Name: Siemens
Model Number: 6GK5528-0AR00-2AR2
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]

Appurtenance:

siemens 6gk5528 0ar00 2ar2 scalance xr528 6m managed layer 3 industrial ethernet switch-1

Overview
Commercial Term
Specifications
Contact info
Description
Function
About Company
Why Choose Us
Other Products
Recommended Products

SIEMENS INDUSTRIAL NETWORKING · SCALANCE XR SERIES

Siemens 6GK5528-0AR00-2AR2 SCALANCE XR528-6M Managed Layer 3 Industrial Ethernet Switch

Managed Ethernet

Layer 3 Integrated

19-inch Rack

Official Siemens product data identifies 6GK5528-0AR00-2AR2 as the SCALANCE XR528-6M managed industrial Ethernet switch with integrated Layer 3 functionality, modular media interfaces, PROFINET IO diagnostics and industrial redundancy support. The information below is arranged for clear sourcing and technical evaluation.

Commercial Term

Supply Ability

In stock

Price

Contact for Jim

Packaging Details

Original new Factory Sealed

Delivery Time

3–7 Days

Payment Terms

T/T

Shipping Method

DHL / FedEx / UPS / TNT

Specifications

TECHNICAL PARAMETER	OFFICIAL VALUE
Transfer rate	10 / 100 / 1,000 / 10,000 Mbit/s
PoE network connections	12
Integrated SFP+ connections	4
Maximum 100 Mbit/s ST multimode ports	24
Maximum 100 Mbit/s ST single-mode ports	24
Maximum 1,000 Mbit/s SC multimode ports	24
Maximum 1,000 Mbit/s SC single-mode ports	24
Pluggable SFP connections	4
Pluggable SFP+ connections	4
Media module connections	6
Operator console connections	1
Management connections	1
Signaling contact connections	1
Power supply connections	1
Redundant voltage supply connections	1
Signaling contact rated voltage	24 V DC
Signaling contact maximum current	0.1 A DC
External supply voltage	24 V DC
Permissible supply voltage range	19.2–28.8 V DC
Input fuse rating	F 15 A / 125 V
Maximum current consumption	11.5 A
Maximum PoE power per port	30 W
Maximum total PoE power	180 W
Operating temperature range	0–60 °C
Storage/transport temperature range	−40–70 °C
Maximum relative humidity	95 %
Protection rating	IP20
Maximum Ethernet telegram length	9,216 bytes
Maximum VLANs	255
Maximum dynamic VLANs	255
Console connection type	RJ11
Management connection type	RJ45
Signaling contact type	2-pole terminal block
Power supply connection type	4-pole terminal block
Installation format	19-inch rack

Contact info

CONTACT

Sales
Jim Pei

Email
[email protected]

Phone/Whatsapp
+86 18020776782

Description

PRODUCT OVERVIEW · 6GK5528-0AR00-2AR2

6GK5528-0AR00-2AR2 is the Siemens SCALANCE XR528-6M managed industrial Ethernet switch with integrated Layer 3 capability and a modular 19-inch rack design. It supports transmission rates up to 10 Gbit/s and accommodates copper, fiber-optic and PoE connections through flexible media modules. The switch provides PROFINET IO diagnostics, network management, VLAN, routing, redundancy and security capabilities for demanding industrial communication networks. This Siemens SCALANCE managed switch is designed for dependable plant-network infrastructure and structured automation connectivity. Its modular architecture helps users adapt network interfaces to changing project requirements. Amikon supplies original industrial automation products with responsive commercial and technical support.

Function

FUNCTION 01

Provides managed switching for industrial Ethernet networks.

FUNCTION 02

Routes traffic between network segments through integrated Layer 3 functionality.

FUNCTION 03

Connects copper, fiber-optic and Power-over-Ethernet devices through modular media interfaces.

FUNCTION 04

Supports structured network segmentation and traffic control.

FUNCTION 05

Provides device, port and communication diagnostics for maintenance teams.

FUNCTION 06

Supports industrial redundancy mechanisms for higher network availability.

FUNCTION 07

Enables centralized configuration and network management.

FUNCTION 08

Integrates into PROFINET-based automation architectures.
