Home > Products > SIEMENS > SIMATIC S7 Series
Siemens 6GK5615-0AA00-2AA2 is the SCALANCE S615 industrial LAN router. Siemens specifies VPN and firewall protection, NAT/NAPT address conversion, connection to SINEMA RC, a five-port switch, one digital input and one digital output.
Brand |
Siemens |
Series |
SCALANCE S |
Article number |
6GK5615-0AA00-2AA2 |
Official description |
SCALANCE S615 LAN router for device and network protection with VPN, firewall, NAT/NAPT, SINEMA RC connection, 5-port switch, 1 digital input and 1 digital output |
|
Article number
|
6GK5615-0AA00-2AA2
|
|
Product designation
|
SCALANCE S615
|
|
Transfer rate
|
10 / 100 Mbit/s
|
|
Network connections
|
5 maximum
|
|
Rated supply voltage
|
24 V DC
|
|
Supply range
|
10.8 to 28.8 V DC
|
|
Typical current at 24 V DC
|
0.2 A
|
|
Rated power loss
|
4 W
|
|
Digital signals
|
1 input and 1 output
|
|
C-PLUG
|
Supported
|
|
Ethernet
|
Five electrical network connections
|
|
Power
|
Five-pole terminal block; redundant supply connection specified
|
|
Digital input
|
One connection via two-pole terminal block
|
|
Digital output
|
One connection via two-pole terminal block
|
|
Storage
|
Removable C-PLUG supported
|
|
Design
|
Compact industrial security appliance
|
|
Protection rating
|
IP20
|
|
Operating temperature
|
-40 to +70 degrees C
|
|
Storage temperature
|
-40 to +80 degrees C
|
|
Transport temperature
|
-40 to +80 degrees C
|
|
Relative humidity
|
Up to 95% at 25 degrees C, non-condensing
|
|
Lifecycle
|
Active product status shown by Siemens; confirm at quotation
|
|
01
|
Match the complete article number 6GK5615-0AA00-2AA2.
|
|
02
|
Confirm required VPN, firewall and NAT/NAPT functions.
|
|
03
|
Verify SINEMA RC architecture and software compatibility.
|
|
04
|
Confirm five-port topology and 10/100 Mbit/s performance.
|
|
05
|
Verify supply, redundant feed, digital I/O and grounding.
|
|
06
|
Confirm firmware, security policy and certificates before deployment.
|
|
Identity
|
Match 6GK5615-0AA00-2AA2 and the complete Siemens description.
|
|
Configuration
|
Confirm series, system, firmware or project compatibility.
|
|
Electrical data
|
Verify supply, signals, loads, wiring and protection.
|
|
Accessories
|
Confirm all separately ordered connectors, BaseUnits or mounting parts.
|
|
Documentation
|
Request the current Siemens data sheet, certificates and manuals.
|
|
Commercial scope
|
Confirm quantity, condition, test status, warranty and dispatch terms.
|
|
Real stock
|
Subject to verification. Request current inventory evidence before quotation.
|
|
Condition
|
New, used or refurbished status must be confirmed for the offered unit.
|
|
Current photos
|
Current unit and nameplate photos are available on request.
|
|
Warranty
|
Available on request and confirmed in the written quotation.
|
|
Dispatch time
|
Subject to verification after quantity, destination and payment terms are confirmed.
|
|
Testing
|
Test status and any test report are subject to verification.
|
|
Payment methods
|
Available on request and stated in the formal quotation.
|
|
Quotation response
|
Response time is subject to verification; send the complete article number and quantity.
|
|
Transaction confidence
|
Company and transaction documents are available on request; use the written quotation and agreed payment terms.
|
|
