Siemens 6GK5734-1FX00-0AA0 SCALANCE W734-1 RJ45 Industrial WLAN Client

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Specifications

Model Number	6GK5734-1FX00-0AA0
WLAN standards	IEEE 802.11a/b/g/h/n
Maximum gross WLAN data rate	300 Mbit/s
Wired Ethernet data rates	10 / 100 Mbit/s
Integrated Ethernet ports	2 × RJ45
Installed radio modules	1 radio
MIMO configuration	2 × 2 MIMO
Spatial streams	2 streams
External antenna connectors	2 × R-SMA sockets
2.4 GHz operating-frequency range	2.41–2.48 GHz, subject to country approval
5 GHz operating-frequency range	4.9–5.8 GHz, subject to country approval
Rated DC supply	24 V DC
Terminal supply range	19.2–28.8 V DC
PoE supply voltage	48 V
Supply terminal	4-pole screw terminal; PoE also supported
Typical current at 24 V DC	0.25 A
Typical PoE current	0.125 A
Typical power loss	6 W
PoE standards	IEEE 802.3af / IEEE 802.3at Type 1 and Type 2
Operating temperature	-20 to +60 °C
Storage / transport temperature	-40 to +85 °C
Maximum relative humidity	95% at 25 °C, non-condensing
Ingress protection	IP30
Minimum enclosure for Zone 2 use	IP54 to EN 60529, subject to installation requirements
Manageable client IP addresses	8 addresses
SNMP versions	v1 / v2 / v3
DHCP roles / option	Client / server; Option 82
Spanning-tree protocols	STP / RSTP / MSTP
Wireless security	WPA / WPA2; IEEE 802.11i
Encryption	TKIP / AES
Authentication	IEEE 802.1X / RADIUS
Access-control lists	MAC-based and management IP-based ACLs
Time synchronization	NTP / SNTP / SIMATIC Time
Safety standards	UL 60950-1 E115352 / CSA C22.2 No. 60950-1
Certification ID	MSN-W1-RJ-E2

Contact info

Sales

Jim Pei

Email

[email protected]

Phone/Whatsapp

+86 18020776782

Description

01

Siemens 6GK5734-1FX00-0AA0 is the SCALANCE W734-1 RJ45 Industrial WLAN client. It connects wired Ethernet devices to a compatible wireless network. The unit has an installed radio and external antenna connections. DC power and the specified Power-over-Ethernet options are supported. This order number is designated for operation outside the USA and Israel, subject to national approvals.

02

The device provides client operation rather than access-point operation. Its wired connections include an integrated Ethernet switch. The supported PLUG options provide configuration storage or licensed industrial wireless functions. Management and security settings must suit the installation. Confirm the destination country and required wireless approvals before ordering.

Diagnostics

01

Wireless client status

Use the client configuration and available management interfaces to investigate the wireless connection.

02

Event reporting

SysLog, SNMP and PROFINET IO diagnosis provide supported monitoring paths.

03

Unsupported monitoring modes

Link check and IP-Alive connection monitoring are not listed for this configuration.

FAQ

01

Can 6GK5734-1FX00-0AA0 operate as an access point?

No. This configuration supports client mode, while access-point mode is not supported.

02

May 6GK5734-1FX00-0AA0 be installed in the USA or Israel?

This order is specified for operation outside those countries. Confirm the destination and national approval before purchase.

03

Are iFeatures enabled on every 6GK5734-1FX00-0AA0?

Some industrial wireless functions require the specified KEY-PLUG. Confirm the required functions and included PLUG before ordering.

04

Can I power 6GK5734-1FX00-0AA0 through Ethernet?

Yes. The documented PoE standards are supported; check the planned supply arrangement.

05

Can you verify the condition and package of 6GK5734-1FX00-0AA0?

Yes. Actual-item photos and package confirmation are available. Each item is tested before delivery with the agreed 12-month warranty.

06

When will a confirmed 6GK5734-1FX00-0AA0 order leave your warehouse?

Available stock is dispatched promptly after payment is received, with shipment tracking provided.
