Siemens 6SL3120-1TE21-8AA3 SINAMICS S120 Single Motor Module In stock

Siemens 6SL3120-1TE21-8AA3 SINAMICS S120 Single Motor Module In stock

Product Name:SINAMICS S120 Single Motor Module

Brand Name:Siemens

Model Number:6SL3120-1TE21-8AA3

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6sl3120 1te21 8aa3 sinamics s120 single motor module in stock-1

Overview
Inquiry now
Specifications
Description
Applications
Environmental Strength
High-Resolution Measurement
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6SL3120-1TE21-8AA3
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Inquiry now

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model:	6SL3120-1TE21-8AA3, Siemens SINAMICS S120 Single Motor Module designed for high-performance industrial drive applications.
Product Type:	Single Motor Module with integrated power electronics for servo and AC motor control.
Input Voltage:	600 V DC link input for stable power conversion and efficient drive operation.
Output Voltage:	400 V AC, three-phase output for industrial motor applications.
Rated Output Current:	18 A continuous output current supporting demanding motion control tasks.
Cooling Method:	Internal air cooling for reliable thermal management during continuous operation.
Communication Interface:	Integrated DRIVE-CLiQ interface for fast digital communication and device integration.
Safety Functions:	Supports Siemens Safety Integrated functions for enhanced operational safety.
Mechanical Design:	Compact Booksize construction optimized for high-density control cabinets.
Dimensions:	Approx. 100 × 300 × 270 mm (W × H × D).
Net Weight:	Approximately 5.06 kg.
Country of Origin:	Germany.

Description

The 6SL3120-1TE21-8AA3 is a high-efficiency Siemens SINAMICS S120 Single Motor Module engineered for demanding industrial motion control and variable-speed drive applications. Designed with a 600 V DC link input and 400 V three-phase AC output, the module delivers up to 18 A of continuous motor current, ensuring stable and precise performance across a wide range of automation systems. Its compact Booksize design allows easy installation while maximizing cabinet space.

Featuring optimized pulse patterns, integrated DRIVE-CLiQ connectivity, and advanced Safety Integrated support, the 6SL3120-1TE21-8AA3 provides fast communication, accurate motor control, and reliable system protection. Internal air cooling enhances thermal efficiency, enabling continuous operation under demanding industrial workloads while reducing maintenance requirements.

Fully compatible with the SINAMICS S120 drive platform and related Siemens motion control solutions, the 6SL3120-1TE21-8AA3 is widely used in machine building, robotics, packaging equipment, conveyor systems, and precision manufacturing where high-performance servo drive technology and dependable motion control are essential.

Applications

Power plants: Controls auxiliary motors, cooling fans, pumps, and high-performance drive systems for reliable plant operation.
Substations: Drives ventilation systems, auxiliary equipment, and industrial motor applications requiring precise speed regulation.
Chemical plants: Supports mixers, dosing equipment, pumps, and continuous process automation with accurate motor control.
Steel mills: Delivers high-performance drive control for rolling mills, conveyors, and heavy-duty production equipment operating under harsh conditions.
Machinery manufacturing plants: Powers CNC machines, robotic workstations, packaging systems, and automated production lines with high dynamic response.
Food and beverage industry: Controls conveyor systems, filling machines, and packaging equipment requiring stable speed regulation.
Logistics and warehousing: Operates automated storage systems, conveyors, and material handling equipment with efficient motion control.

Environmental Strength

Engineered for continuous industrial operation under demanding production conditions.
Internal air cooling improves thermal stability and extends equipment service life.
Compact Booksize housing reduces cabinet space while maintaining excellent heat dissipation.
Designed for environments with continuous machine operation and frequent load variations.
High electromagnetic compatibility supports reliable operation in complex automation systems.
Industrial-grade construction minimizes downtime and maintenance requirements.
Suitable for manufacturing, process industries, logistics, and heavy industrial automation.
Robust Siemens design ensures dependable long-term performance in mission-critical applications.

High-Resolution Measurement

Optimized pulse pattern technology enables smooth motor torque and speed regulation.
Fast digital control improves positioning precision and motion stability.
High-speed DRIVE-CLiQ communication enhances feedback accuracy between drive and controller.
Supports precision servo applications requiring rapid response and repeatable positioning.
Stable current regulation improves motor efficiency and minimizes mechanical vibration.
Advanced drive algorithms provide accurate speed control across varying load conditions.
Suitable for high-performance motion systems requiring consistent dynamic accuracy.
Delivers reliable control for precision manufacturing and automated production equipment.

FAQ

Q1: What is the primary function of the 6SL3120-1TE21-8AA3?
A1: The 6SL3120-1TE21-8AA3 is a SINAMICS S120 Single Motor Module designed to control industrial AC and servo motors with high efficiency and precision.

Q2: What are the input and output ratings of the 6SL3120-1TE21-8AA3?
A2: It operates with a 600 V DC input and provides a 400 V three-phase AC output with a rated current of 18 A.

Q3: Does the 6SL3120-1TE21-8AA3 support DRIVE-CLiQ communication?
A3: Yes. The module includes an integrated DRIVE-CLiQ interface for fast digital communication and simplified system integration.

Q4: Which cooling method is used by the 6SL3120-1TE21-8AA3?
A4: It features internal air cooling, providing efficient thermal management for continuous industrial operation.

Q5: Which industries commonly use the 6SL3120-1TE21-8AA3?
A5: The module is widely applied in robotics, machine tools, packaging equipment, conveyor systems, material handling, and advanced manufacturing automation requiring precise motor control.
