SIEMENS SIMATIC PM 1507 6EP1332-4BA00 Stabilized Power Supply 24 V DC / 3 A

SIEMENS SIMATIC PM 1507 6EP1332-4BA00 Stabilized Power Supply 24 V DC / 3 A

6EP1332-4BA00

SIMATIC PM 1507 stabilized power supply for S7-1500

120/230 V AC24 V DC3 AS7-1500 rail

Selection note: Confirm mains conditions, cabinet layout and the absence of required Ex approval before quotation.

Overview
Data
Interfaces
Protection
Installation
Checklist
Commercial
FAQ
Models
Recommended Products

Product Overview

The Siemens SIMATIC PM 1507 6EP1332-4BA00 is a stabilized power supply for the S7-1500 system. It accepts 120/230 V AC with automatic range selection and provides a regulated 24 V DC / 3 A output.

Applications

Supplying SIMATIC S7-1500 system components
Generating regulated 24 V DC inside control cabinets
Machine and process automation cabinets with a compatible S7-1500 mounting rail
Retrofit or replacement projects after mechanical and electrical verification

Technical basis: official Siemens Industry Mall technical data for 6EP1332-4BA00.

Data

Data

Brand Siemens	Series SIMATIC PM 1507	Input 120/230 V AC, automatic range selection
Input ranges 85-132 V AC / 170-264 V AC	Output 24 V DC / 3 A	Line frequency 45-65 Hz
Mains buffering Minimum 20 ms at rated output	Dimensions 50 x 147 x 129 mm

Interfaces

Interfaces

Input terminals	L, N and PE screw terminals
Input conductor range	0.5-2.5 mm2
Output terminals	L+ and M, two spring-loaded terminals
Output conductor range	0.5-2.5 mm2
Terminal design	Removable input and output terminals
Isolation	Controlled, isolated DC output

Protection

Protection

Operating temperature 0 to 60 C with natural convection in horizontal mounting	Vertical mounting 0 to 40 C	Storage and transport -40 to +85 C
Humidity 5-95%, no condensation	Output tolerance 1%	Ex approval Not included for 6EP1332-4BA00

Installation

Installation

1	Use the specified SIMATIC S7-1500 mounting rail; DIN rail or wall mounting is not listed.
2	Provide 40 mm clearance above and below the device.
3	Verify the 120/230 V AC range and protective device selection.
4	Wire L, N, PE, L+ and M with the specified conductor sizes.
5	Check polarity and output voltage before connecting the load.

Checklist

Checklist

Confirm complete MLFB 6EP1332-4BA00.
Confirm 24 V DC / 3 A is adequate for the load calculation.
Confirm S7-1500 rail mounting and cabinet clearances.
Confirm no Ex approval is required for the application.
Request current unit and nameplate photographs before quotation.

Commercial

Commercial

Stock status	Confirm before quotation
Condition	New, used or refurbished status is subject to verification
Current photographs	Available on request
Warranty	Available on request
Dispatch time	Confirm before quotation
Test status	Scope and records are subject to verification
Payment methods	Available on request
Quotation response	Available on request
Transaction process	Request a formal quotation, traceability details and agreed trade terms

FAQ

FAQ

Q: What is the rated output?
A: The official technical data specifies 24 V DC at 3 A.

Q: Does it select 120 or 230 V automatically?
A: Yes. Siemens lists automatic range selection.

Q: Can it mount on a standard DIN rail?
A: The official data lists the S7-1500 mounting rail, not DIN rail or wall mounting.

Q: Does this MLFB include Ex approval?
A: No. The official technical data states without Ex approval.

Q: What is the dispatch time?
A: Confirm before quotation. Dispatch depends on the verified offered unit and transaction terms.
