SIEMENS · SIMATIC S7-1500
6ES7522-1BH10-0AA0
DQ 16x24 V DC/0.5 A BA Digital Output Module
|
|
|
Order check: Confirm the complete article number, hardware version and host-system compatibility before quotation.
|
OFFICIAL PRODUCT OVERVIEW
DQ 16x24 V DC/0.5 A BA Digital Output Module
The SIMATIC S7-1500 DQ 16x24 V DC/0.5 A BA is a digital output module for switching 24 V DC field loads. Its 16 outputs are organized in two groups of eight, supporting structured cabinet wiring and channel-level diagnostics within an S7-1500 station.
|
FUNCTIONS & APPLICATIONS
• Machine and process output switching
• Actuator, valve and indicator control • Distributed cabinet output expansion • Safety-oriented shutdown up to SIL 2 / PL d when used in an approved system |
|
Outputs
|
16 digital outputs
|
|
Rated voltage
|
24 V DC
|
|
Output current
|
0.5 A per channel
|
|
Channel grouping
|
2 groups of 8
|
|
Maximum group current
|
4 A per group
|
|
Module family
|
SIMATIC S7-1500
|
|
Field connection
Push-in front connector
|
System connection
S7-1500 backplane bus
|
Diagnostics
Channel and module status via the controller
|
|
Mounting
|
S7-1500 mounting rail
|
|
Protection
|
IP20 when installed as specified
|
|
Operating conditions
|
Use within the limits stated in the Siemens technical data
|
|
Handling
|
Observe ESD and cabinet installation requirements
|
|
INSTALLATION CHECK
1. Confirm the full article number and hardware version before replacement.
2. Check load voltage, current demand and channel grouping. 3. Use the approved S7-1500 front connector and wiring method. 4. Verify the CPU hardware configuration and safety concept before commissioning. |
SELECTION NOTE
Match before purchase
Use the complete Siemens article number and host-system data as the primary ordering reference.
|
|
1Complete Siemens article number
|
2Required channel count and load type
|
3Supply voltage and group current
|
|
4Front connector availability
|
5Hardware configuration and firmware project
|
6Current unit and nameplate photos
|
|
Stock
|
Confirm before quotation
|
|
Condition
|
Subject to verification
|
|
Photos
|
Current unit and nameplate photos available on request
|
|
Testing
|
Test scope available on request
|
|
Warranty
|
Confirm before quotation
|
|
Dispatch
|
Subject to verification
|
|
Payment
|
Available options confirmed with quotation
|
|
Quotation
|
Response time confirmed after inquiry
|
|
6ES7522-1BH00-0AB0
|
6ES7522-1BL00-0AB0
|
|
6ES7522-1BL01-0AB0
|
6ES7521-1BH10-0AA0
|
|
6ES7521-1BH50-0AA0
|
6ES7521-1BL10-0AA0
|
|
6ES7512-1CK01-0AB0
|
6ES7515-2RM00-0AB0
|
|
6ES7136-6BA00-0CA0
|
6ES7136-6BA01-0CA0
|
|
COMMON QUESTIONS
FAQ and request quote
Is this exact article number available?
Availability is confirmed against the requested quantity and destination before quotation.
Can I receive current photos and a test statement?
Both are available on request and remain subject to the quoted unit and agreed test scope.
What should be checked before replacement?
Confirm the full article number, output load, connector, channel grouping and project configuration. REQUEST AVAILABILITY AND QUOTATION
|
