Product Name:proximity measurement system
Brand Name:Vibro-Meter
Model Number:EA402 913-402-000-013
Country of Origin:Switzerland
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Vibro-Meter |
Model Number: |
EA402 913-402-000-013 |
Country of Origin: |
Switzerland |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Product Model | EA402 |
| Part Number | 913-402-000-013 |
| Cable Type | 70 Ω FEP coaxial cable |
| Conductor Diameter | Ø3.6 mm |
| Extension Length Range | 3.0 m to 9.5 m options |
| Connection Type | Self-locking miniature coaxial connectors |
| Operating Temperature | -40°C to +200°C (with protection) |
| Storage Temperature | -40°C to +85°C |
| Dimensions | Cable Ø3.6 mm (typical) |
| Weight | Approx. N/A (depends on configuration) |
The EA402 913-402-000-013 extension cable is part of Meggitt’s vibro-meter® proximity measurement architecture, designed to extend the reach of TQ4xx eddy-current transducers such as TQ442 while maintaining signal integrity over long distances. It enables flexible system configuration for vibration and position monitoring in industrial machinery environments.
Paired with the IQS450 signal conditioner, the EA402 ensures stable transmission of high-frequency measurement signals with minimal loss, supporting both voltage and current output systems. It is fully compatible with VM600Mk2/VM600 and VibroSmart® monitoring platforms.
Built with rugged FEP-insulated coaxial construction and precision-engineered connectors, the EA402 supports demanding environments including hazardous Ex-rated installations, offering reliable mechanical protection and long-term operational stability in turbine, compressor, and rotating equipment applications.
Q1: What is EA402 used for?
A1: It is used to extend the connection between TQ4xx proximity sensors and IQS450 signal conditioners in vibration monitoring systems.
Q2: Is EA402 compatible with hazardous areas?
A2: Yes, it supports Ex-rated configurations when used with certified TQ and IQS systems.
Q3: What cable type does EA402 use?
A3: It uses a 70 Ω FEP-insulated coaxial cable designed for industrial environments.
Q4: Can EA402 be used with VM600 systems?
A4: Yes, it is fully compatible with VM600 and VibroSmart® monitoring platforms.
Q5: What is the operating temperature range?
A5: It typically operates from -40°C up to +200°C depending on installation protection.
|
