Product Name: Digital DC Input Module
Brand Name: Allen-Bradley
Model Number: 1794-IB16XT
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
The Allen-Bradley 1794-IB16XT is a 16-point Digital DC Input Module from the FLEX I/O XT (Bulletin 1794) series, designed for distributed industrial automation systems operating in demanding environments. It accepts 24 VDC sinking (PNP) digital input signals from field devices such as proximity sensors, push buttons, and limit switches. With its compact design and extended operating temperature range, the module is well suited for applications requiring reliable remote I/O performance in harsh industrial conditions.
Monitors digital input signals from field devices.
Interfaces 24 VDC sensors, switches, and other discrete input devices with PLC systems.
Transmits real-time input status to distributed control systems.
Supports high-speed digital signal acquisition for machine automation.
Expands digital input capacity within FLEX I/O XT installations.
Enables reliable remote I/O operation in industrial environments.
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | AB 1794-IB16XT Digital DC Input Module |
| Manufacturer | Allen-Bradley |
| Product Type | Digital DC Input Module |
| Part Number | 1794-IB16XT |
| Weight | 0.08kg |
| Estimated shipping dimensions | 9.3x5.3x4.8cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Product Series | Flex I/O XT (Bul. 1794) |
| Component Type Fieldbus I/O | Digital Input Module |
| Number of Digital Inputs | 16 qty |
| Digital Input Type | 24V DC Sinking (PNP) type |
| Power Supply | 24V DC |
| Operating Temperature, Max | 70 °C max |
| Operating Temperature, Min | -20 °C min |
Extended Temperature Capability
With an operating range of -20 °C to 70 °C, the 1794-IB16XT performs reliably in harsher environments where standard digital input modules may have more limited temperature ratings.
High Input Density
The module provides 16 digital inputs in a compact housing, allowing efficient use of control cabinet space while reducing the number of required I/O modules.
Optimized for Distributed I/O
As part of the FLEX I/O XT platform, it enables flexible remote installation close to field devices, reducing wiring costs and simplifying system architecture.
Reliable Signal Acquisition
Accurately captures 24 VDC digital input signals from industrial sensors and switches, ensuring dependable machine monitoring and control.
Easy System Expansion
The modular FLEX I/O XT design allows users to expand digital input capacity quickly without extensive modifications to the existing automation system.
Industrial-Grade Durability
Built for continuous operation in demanding industrial environments, delivering stable performance and long service life.
Seamless Allen-Bradley Integration
Fully compatible with Allen-Bradley FLEX I/O XT and Logix-based control systems, enabling straightforward configuration, efficient commissioning, and reliable communication.
