ABB AX561 1TNE968902R1301 Analog input/output module Original new

ABB AX561 1TNE968902R1301 Analog input/output module Original new

Product Name:Analog input/output module

Brand Name:ABB

Model Number:AX561 1TNE968902R1301

Country of Origin:SWEDEN

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	ABB
Model Number:	AX561 1TNE968902R1301
Country of Origin:	SWEDEN
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	AX561 1TNE968902R1301
Manufacturer	ABB
Product Type	Analog Input/Output Module
I/O Configuration	4 Analog Inputs, 2 Analog Outputs
Input Signal	Voltage (U), Current (I)
Output Signal	Voltage (U), Current (I)
Analog Input Resolution	12-bit
Analog Output Resolution	12-bit
Connection Type	Pluggable terminal
Protection Rating	IP20
Operating Temperature	0°C to +60°C
Storage Temperature	-40°C to +70°C
Communication	1-wire
Compatible System	ABB S500 Distributed I/O, AC500-eCo PLC
Dimensions (W × H × D)	34 × 74 × 135 mm
Net Weight	0.122 kg

Description

ABB AX561 1TNE968902R1301 is a high-performance analog input/output module designed for the ABB S500 distributed I/O platform and AC500-eCo PLC systems. Featuring 4 configurable analog inputs and 2 analog outputs supporting both voltage and current signals, the module enables stable and accurate signal acquisition for demanding industrial automation environments. Models such as AX561, AX560, and other ABB S500 I/O modules provide flexible expansion solutions for modern control systems.

With a compact DIN-rail design, pluggable terminal connections, and 12-bit analog resolution, AX561 1TNE968902R1301 simplifies installation while delivering reliable measurement and output performance. Its IP20 enclosure and wide operating temperature range make it suitable for continuous industrial operation with minimal maintenance.

Designed for process automation, machine control, and distributed I/O architectures, AX561 1TNE968902R1301 supports precise analog data exchange between field devices and PLC controllers. It is widely used in manufacturing, energy, water treatment, and infrastructure applications where dependable signal processing and long-term operational stability are essential.

Applications

Power plants: Used for turbine control systems, analog process signal acquisition, and power generation monitoring.
Substations: Supports voltage and current signal collection for protection, monitoring, and automation systems.
Chemical plants: Integrates transmitters, sensors, and control devices for continuous process automation.
Oil & gas facilities: Provides reliable analog measurement for pressure, flow, level, and temperature control applications.
Water treatment plants: Connects field instrumentation to PLC systems for pump, valve, and process regulation.
Steel mills: Performs accurate analog monitoring in high-temperature and high-interference production environments.
Machinery manufacturing plants: Enables precise analog control for automated production lines, robotics, and packaging equipment.

Features

High-density analog I/O: Provides 4 analog inputs and 2 analog outputs in one compact module.
Dual signal compatibility: Supports both voltage and current input/output signals.
12-bit precision: Ensures stable and accurate analog data acquisition and control.
Compact installation: Slim DIN-rail design saves cabinet space.
Pluggable terminals: Simplifies wiring, maintenance, and module replacement.
Industrial reliability: Designed for continuous operation in demanding automation systems.
Wide compatibility: Seamlessly integrates with ABB S500 and AC500-eCo platforms.

Functions

Collects analog voltage and current signals from field instruments.
Outputs accurate analog control signals to actuators and process equipment.
Interfaces transmitters, sensors, and PLC controllers.
Supports distributed industrial I/O architectures.
Improves process accuracy and real-time control performance.
Enables stable analog communication in automation systems.
Reduces wiring complexity and simplifies system expansion.

FAQ

Q1: What is the primary function of the AX561 1TNE968902R1301?
A1: It provides 4 analog inputs and 2 analog outputs for voltage and current signal processing in ABB automation systems.

Q2: Which PLC platform is compatible with the AX561?
A2: It is designed for ABB S500 Distributed I/O and AC500-eCo programmable logic controllers.

Q3: What analog signal types does the module support?
A3: The module supports both voltage (U) and current (I) input and output signals.

Q4: What is the analog resolution of the AX561 1TNE968902R1301?
A4: Both analog inputs and outputs provide 12-bit resolution for reliable measurement accuracy.

Q5: Is the AX561 suitable for industrial automation environments?
A5: Yes. Its IP20 housing, compact design, and wide operating temperature range make it well suited for industrial process control and distributed automation applications.
