Allen-Bradley 1734-IE4S Point IO Safety Analog Input Module

Allen-Bradley 1734-IE4S Point IO Safety Analog Input Module

Product Name: Point IO Safety Analog Input Module

Brand Name: Allen-Bradley

Model Number: 1734-IE4S

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

allen bradley 1734 ie4s point io safety analog input module-1

Overview
Contact Us
Specifications
Description
Functions
Advantage
Why Choose US
Other Products
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales:	Email:	Whatsapp:
*Jim Pei*	*[email protected]*	*+86 18020776782*

Specifications

Product Name	Allen-Bradley 1734-IE4S Point IO Safety Analog Input Module
Manufacturer	Allen-Bradley
Product Type	Point IO Safety Analog Input Module
Part Number	1734-IE4S
Weight	0.06kg
Estimated shipping dimensions	2.3x5.6x7.5cm
Place of shipment	Xiamen, China
Country of origin	USA
Inputs per module	4 single-ended
Input voltage mode ranges	±5V, ±10V, 0…5V, 0…10V
Input current mode ranges	0…20 mA, 4…20 mA
Tachometer frequency range	1…1000 Hz
Tachometer overrange threshold	1 kHz
ADC resolution	12 bits
Voltage mode input impedance	> 200K Ohms
Current mode input impedance	<100 Ohms
Tachometer mode input impedance	> 200K Ohms
Data value format	16-bit, two’s complement
POINTBus current, max	110 mA @ 5V
Power dissipation, max	2.2 W
Thermal dissipation	7.5 BTU/hr
Power bus, operating supply voltage, nom	24V DC
Power bus, operating voltage range	19.2…28.8V DC
Input filter time, OFF to ON(1)	0…126 ms (in 6 ms increments)
Operating temperature	-20...55 °C (-4...131 °F)
Nonoperating Temperature	-40...85 °C (-40...185 °F)
Relative humidity	5...95% non-condensing
Vibration	5 g @ 10…500 Hz

Description

The Allen-Bradley 1734-IE4S Point I/O Safety Analog Input Module is a safety-rated analog input module designed for distributed industrial automation and safety control applications. It provides four single-ended analog input channels with support for multiple voltage and current signal ranges, including ±5 V, ±10 V, 0–10 V, 0–20 mA, and 4–20 mA. The module also supports tachometer input functions, enabling flexible monitoring of analog signals, speed feedback, and process variables. With compact Point I/O architecture, high-resolution signal conversion, and reliable operation in industrial environments, it helps improve safety system performance while reducing installation complexity.

Functions

Acquires analog signals from sensors, transmitters, and field devices.

Converts voltage and current input signals into digital data for controller processing.

Supports multiple analog input ranges for flexible device compatibility.

Provides tachometer signal measurement for speed monitoring applications.

Transfers safety-related analog data through the Point I/O system.

Supports configurable input filtering to improve signal stability.

Enables distributed installation close to field devices for simplified system wiring.

Advantage

Compared with standard analog input modules, the Allen-Bradley 1734-IE4S provides safety-oriented signal processing, flexible input configuration, and compact distributed I/O integration, making it suitable for demanding industrial control and safety applications.

Safety-Rated Analog Processing: Designed for safety applications, helping improve system reliability when monitoring critical analog signals.
Flexible Signal Compatibility: Supports multiple voltage, current, and tachometer input modes, allowing connection with a wide range of industrial sensors and transmitters.
Four-Channel Input Design: Provides four analog input channels in a compact module size, reducing installation space requirements.
High-Resolution Data Conversion: Features 12-bit ADC resolution for accurate analog signal measurement and improved process monitoring.
Compact Point I/O Architecture: Enables distributed installation near field devices, reducing wiring requirements and simplifying system expansion.
Reliable Industrial Performance: Supports wide operating temperature ranges, vibration resistance, and stable operation in industrial environments.
Efficient System Integration: Designed for Allen-Bradley Point I/O platforms, providing seamless communication with safety controllers and automation systems.
