Product Name:High Voltage DC PIM
Brand Name:Bently Nevada
Model Number:106M2686-01 115M7750-01
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
106M2686-01 115M7750-01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Details |
|---|---|
| Product Name | AC Power Supply & DC PIM Module Set |
| Model Numbers | 106M2686-01 / 115M7750-01 |
| System Series | Bently Nevada 3500/15 |
| Product Type | Power Supply / Power Input Module |
| Function | Power conversion & input regulation |
| Input Type | Universal AC / High Voltage DC |
| AC Input Range | 85–264 Vac rms |
| DC Input Range | 88–140 Vdc |
| Frequency Range | 47–63 Hz |
| Rack Compatibility | Bently Nevada 3500 series rack |
| Installation Type | Half-height rack mounted module |
| Dimensions (Power Module) | 120.7 × 50.8 × 251.5 mm |
| Dimensions (PIM) | 120.7 × 25.4 × 114.3 mm |
| Net Weight | 1.39 kg (module) / 0.34 kg (PIM) |
| Operating Temperature | -30°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 95% non-condensing |
The 106M2686-01 together with 115M7750-01 is a high-reliability power interface solution designed for the Bently Nevada 3500 machinery protection system. The 106M2686-01 module is engineered to deliver stable AC power conversion, ensuring consistent energy distribution for rack-mounted monitoring and control components.
The 115M7750-01 High Voltage DC PIM (Power Input Module) provides efficient DC power input regulation, supporting secure and stable system operation under demanding industrial conditions. Both modules are designed for integration within redundant or single power supply architectures in 3500/15 racks.
Built for industrial-grade performance, this power supply and input module combination ensures continuous system availability, minimizes downtime risk, and supports reliable operation in critical monitoring environments such as rotating machinery protection systems.
Q1: What is 106M2686-01 used for?
A1: It is used as an AC power supply module for Bently Nevada 3500 systems.
Q2: What is 115M7750-01?
A2: It is a high voltage DC Power Input Module (PIM) for the 3500/15 rack system.
Q3: Can these modules be used together?
A3: Yes, they can operate in combined AC/DC or redundant power configurations.
Q4: What system are they compatible with?
A4: They are designed for the Bently Nevada 3500 machinery protection system.
Q5: What is the operating temperature range?
A5: They operate from -30°C to +65°C in industrial environments.
| Number | Description |
|---|---|
| 106M1079-01 | Universal AC Power Supply Module |
| 106M1081-01 | Universal AC Power Input Module |
| 129486-01 | Legacy High Voltage DC Power Supply Module |
| 129478-01 | Legacy High Voltage DC Power Input Module |
| 133292-01 | Legacy Low Voltage DC Power Supply Module |
| 133300-01 | Legacy Low Voltage DC Power Input Module |
| 114M5329-01 | High Voltage DC Power Supply Module |
| 115M7750-01 | High Voltage DC PIM (Power Input Module) |
| 114M5330-01 | Low Voltage DC Power Supply Module |
| 114M5335-01 | Low Voltage DC PIM (Power Input Module) |
| 01720025 | Replacement Fuse for AC Power Input Module and Legacy HV DC Power Input Module |
| 01720045 | Replacement Fuse for Low Voltage DC Input Modules |
| 120M3877 | Fast-blow Replacement Fuse 5A / 500Vac (6.3×32mm) |
| 131150-01 | Power Supply Blank Front Panel (with screws) |
| 128085-01 | Power Supply Rear Input Connector Cover |
| 04310251 | Screw for Power Supply Input Cover |
| 129767 | 3500/15 Power Supply User Guide |
| 118M0915-01 | Replacement Connector for Universal AC Power Input Module |
| 118M0915-02 | Replacement Connector for DC Power Input Module |
| 129M0198 | Replacement Fuse for High Voltage DC Power PIM |
