Product Name:Proximity Probe Housing Assemblies
Brand Name:Bently Nevada
Model Number:32000-29-05-04-090-07-02
Country of Origin:USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
32000-29-05-04-090-07-02 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Details |
|---|---|
| Product Model | 32000-29-05-04-090-07-02 |
| Product Type | Proximity Probe Housing Assembly |
| Probe System | 3300 XL Proximity Probe Compatible |
| Probe Type | 8 mm Proximity Probe with Connector Protector |
| Cable Length | 0.5 m |
| Standoff Adapter (C) | 90 mm |
| Probe Penetration (D) | 70 mm (configuration dependent) |
| Mounting Thread | 3/4-14 NPT |
| Fittings Option | PG21 x M20 / dual fitting configuration |
| Housing Material | Glass-reinforced PPS thermoplastic |
| Metal Material | AISI 303 / 304 stainless steel |
| O-Ring Material | Neoprene |
| Protection Rating | IP66 / NEMA 4X |
| Operating Temperature | -51°C to +177°C |
| Weight | Approx. 1.2 kg |
| Dimension (Housing Length) | Adjustable 25–760 mm range |
| Installation Type | Radial vibration / Keyphasor measurement support |
The 32000-29-05-04-090-07-02 proximity probe housing assembly is engineered for reliable installation of vibration and displacement monitoring probes in rotating machinery systems. It is widely used in radial measurement applications, ensuring stable signal output for condition monitoring and machinery protection in industrial environments.
The 32000-29-05-04-090-07-02 is part of the advanced 31000/32000 housing series, designed with high-strength PPS thermoplastic and stainless-steel structural components. This combination delivers strong resistance to corrosion, moisture, and mechanical stress, making it suitable for long-term operation in demanding industrial conditions.
Compatible with 3300 XL proximity transducer systems, the 32000-29-05-04-090-07-02 supports external probe access for easy adjustment and replacement. It is designed in compliance with API 670 standards and is widely used in predictive maintenance and critical asset protection systems.
Power plants: Used for generator set monitoring, turbine vibration measurement, and relay protection systems
Substations: Enable bus differential control, line protection, and switchyard signal acquisition
Chemical plants: Integrate automation control systems and intrinsically safe signal monitoring
Steel mills: Operate in high-temperature and strong electromagnetic interference environments for equipment control
Machinery manufacturing plants: Applied in automated production lines, robotics systems, and packaging equipment control
Q1: What is the main purpose of the 32000-29-05-04-090-07-02 housing?
A1: It provides stable mounting and protection for proximity probes used in vibration monitoring systems.
Q2: Which probe system is compatible with this housing?
A2: It is compatible with the Bently Nevada 3300 XL proximity transducer system.
Q3: Can the probe be serviced without removing the machine cover?
A3: Yes, it allows external access for probe adjustment and replacement.
Q4: Is this housing suitable for harsh industrial environments?
A4: Yes, it uses PPS and stainless steel materials for corrosion and impact resistance.
Q5: Does it comply with industrial standards?
A5: Yes, it is designed in accordance with API 670 machinery protection standards.
|
Number |
Description |
|
148722-01 |
3300 XL Test Plug with three color-coded 1-meter leads and banana plugs for testing Proximitor Sensor performance without disconnecting field wiring. |
|
04310310 |
3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor installation. |
|
03200006 |
Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors. |
|
40113-02 |
Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools. |
|
136536-01 |
Connector protector adapter for compatibility with pre-1998 installation tools used with 75Ω ClickLoc connectors. |
|
40180-02 |
Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables. |
|
03839410 |
75Ω triaxial male connector protector for extension cable connections, providing environmental protection against moisture and contaminants. |
|
03839420 |
75Ω triaxial female connector protector for probe and extension cable connections, providing environmental sealing and connector protection. |
|
04301007 |
3/8-24 probe lock nut with dual safety-wire holes for secure probe mounting in vibration-prone applications. |
|
04301008 |
M10 × 1 probe lock nut with dual safety-wire holes for secure installation and retention of proximity probes. |
|
330153-01 |
3300 XL Connector Kit containing male and female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for cable termination and maintenance. |
