Product Name:Proximity Probe Housing Assemblies
Brand Name:Bently Nevada
Model Number:32000-30-05-10-088-07-02
Country of Origin:USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
32000-30-05-10-088-07-02 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Product Model | 32000-30-05-10-088-07-02 |
| Product Type | Metric Proximity Probe Housing Assembly |
| Probe Type | 3300 XL 8 mm Probe with Connector Protector |
| Probe Cable Length | 0.5 m (20 in) |
| Standoff Adapter Length (C) | 100 mm |
| Probe Penetration Length (D) | 88 mm |
| Fitting Option | PG21 × M20 Fitting, Two Plugs |
| Mounting Thread | 3/4-14 NPT |
| Housing Material | Glass-Reinforced PPS Thermoplastic with Conductive Fibers |
| Sleeve Material | AISI 304 Stainless Steel |
| Outer Sleeve & Screws | AISI 303 Stainless Steel |
| O-Ring Material | Neoprene |
| Protection Rating | NEMA 4X, IP66 |
| Operating Temperature | -51°C to +177°C (-60°F to +351°F) |
| Recommended Retaining Nut Torque | 29.4 N·m (260 in·lb) |
| Housing Impact Resistance | Up to 7 Joules (CSA Verified) |
| Typical Housing Strength | Supports 912 N (205 lb) Load |
| Weight | Approx. 1.2 kg (2.6 lb) |
| Maximum C + D Dimension | 394 mm (for 0.5 m probe cable) |
Bently Nevada 32000-30-05-10-088-07-02 is a metric proximity probe housing assembly engineered to provide reliable mechanical protection and convenient external access for vibration and shaft monitoring systems. Designed for use with the 3300 XL 8 mm Proximity Probe, this housing simplifies probe installation, gap adjustment, and maintenance without requiring machine disassembly, helping reduce downtime in critical rotating equipment applications.
The 32000-30-05-10-088-07-02 assembly incorporates a corrosion-resistant PPS housing combined with stainless-steel hardware, delivering excellent durability in demanding industrial environments. Its rugged construction supports long-term operation in power generation, oil and gas, petrochemical, and heavy manufacturing facilities where dependable condition monitoring is essential.
Compatible with various 3300 XL Series transducer systems, including 3300 XL 8 mm, 3300 XL 11 mm, and 3300 XL NSv solutions, the housing meets API 670 requirements for externally mounted probe installations. The design enhances environmental protection while ensuring accurate vibration data acquisition for predictive maintenance and machinery protection programs.
Power Plants: Used for turbine vibration monitoring, generator condition monitoring, and rotating equipment protection
Oil & Gas Facilities: Applied in compressor monitoring, gas turbine diagnostics, and machinery protection systems
Petrochemical Plants: Used for pump monitoring, process equipment diagnostics, and predictive maintenance systems
Steel Mills: Suitable for rolling mill monitoring, heavy equipment protection, and high-temperature environments
Machinery Manufacturing Plants: Applied in automated production lines, robotics systems, and industrial testing equipment
Q1: What is the primary purpose of the 32000-30-05-10-088-07-02 housing assembly?
A1: It provides mechanical and environmental protection for proximity probes while allowing external access for adjustment and maintenance.
Q2: Which probe is included with the 32000-30-05-10-088-07-02 configuration?
A2: This configuration includes a 3300 XL 8 mm proximity probe with a connector protector.
Q3: Is the 32000 housing suitable for hazardous industrial environments?
A3: Yes, when installed with approved transducer systems and appropriate barriers, it can be used in intrinsically safe applications.
Q4: Does the housing meet industry machinery protection standards?
A4: Yes, the design complies with API 670 requirements for externally mounted proximity probe housings.
Q5: Can the probe be replaced without dismantling the machine?
A5: Yes, the housing allows external probe access, enabling replacement and gap adjustment without machine disassembly.
| Number | Description |
|---|---|
| 03813103 | Chrome-plated Zinc Conduit Fitting, 3/4-14 NPT |
| 03818100 | AISI 316 Stainless Steel Conduit Fitting, 3/4-14 NPT |
| 03818101 | AISI 316 Stainless Steel Conduit Fitting, PG21 x M25 |
| 03818102 | AISI 316 Stainless Steel Conduit Fitting, PG21 x M20 |
| 03818103 | AISI 316 Stainless Steel Conduit Fitting, PG21 x PG11 |
| 03818104 | AISI 303 Stainless Steel Cable Gland, PG11 |
| 03818105 | AISI 316 Stainless Steel Cable Gland, M20 |
| 03818111 | Nickel-plated Brass Conduit Fitting, PG21 x M20 |
| 26650-01 | AISI 303 Stainless Steel Reducer, 3/4-14 NPT to 1/2-14 NPT |
