Brand: Bently Nevada
Series: 3300 XL 11 mm
Model: 330703-000-090-50-02-00
Official description: 3300 XL 11 mm Probe, M14 x 1.5 Thread, Without Armor
Official source: Baker Hughes Bently Nevada datasheet 146256 Rev. T.
Configuration note: A 5 m probe must be used with the 5 m 3300 XL 11 mm Proximitor Sensor; confirm the complete system before quotation.
The 3300 XL 11 mm system provides non-contacting vibration and displacement measurement with extended linear range. Official applications include axial thrust position, ramp differential expansion, reciprocating-compressor rod position or rod drop, tachometer and zero-speed measurement, and Keyphasor phase reference.
|
Probe type
|
3300 XL 11 mm standard-mount metric probe, M14 x 1.5 thread, without armor
|
|
Unthreaded length option 000
|
0 mm
|
|
Overall case length option 090
|
90 mm
|
|
Total length option 50
|
5.0 m (16.4 ft)
|
|
Connector option 02
|
Miniature coaxial ClickLoc connector, standard cable
|
|
Approval option 00
|
Agency approval not required
|
|
System linear range
|
4.0 mm (160 mils), approximately 0.5 to 4.5 mm from target
|
|
System scale factor
|
3.94 V/mm (100 mV/mil) ±10%
|
|
Recommended gap
|
2.5 mm (100 mils)
|
|
System frequency response
|
0 to 8 kHz, +0/-3 dB typical
|
The unarmored metric probe uses an M14 x 1.5 standard-mount case, PPS tip, AISI 304 stainless-steel case and 75 ohm FEP-insulated triaxial cable. Option 02 supplies a miniature coaxial ClickLoc connector without a connector protector.
|
Probe operating and storage
|
-52°C to +177°C (-62°F to +351°F)
|
|
Pressure-seal caution
|
Exposure below -34°C (-30°F) may cause premature pressure-seal failure
|
|
Relative humidity
|
100% condensing, non-submersible when connectors are protected
|
|
Approval option
|
00 means agency approval is not required
|
|
Target basis
|
Published system performance uses an AISI 4140 steel target at least 31 mm diameter
|
Use this 5.0 m probe only with the 5 m 3300 XL 11 mm Proximitor Sensor; do not add an extension cable unless the confirmed system configuration requires it. Verify M14 x 1.5 thread engagement does not exceed 21 mm, confirm target size and cross-talk clearance, and set the system gap to 2.5 mm after compatibility checks.
|
Physical stock
|
Confirm before quotation
|
|
Condition: New, Used or Refurbished
|
Subject to verification for the quoted unit
|
|
Current product and nameplate photos
|
Available on request
|
|
Warranty period
|
Available on request and confirmed in the quotation
|
|
Dispatch time
|
Confirm before quotation
|
|
Testing status and scope
|
Subject to verification; available records can be requested
|
|
Payment methods
|
Available on request and stated on the proforma invoice
|
|
Quotation response time
|
Available on request
|
|
Transaction confidence
|
Itemized quotation, company details, invoice, pre-shipment verification and shipment records are provided as applicable
|
Is this actual stock?
Confirm before quotation for the requested quantity.
Is the unit new, used or refurbished?
Subject to verification for the specific unit offered.
Can current product and nameplate photos be provided?
Available on request before order confirmation.
What is the warranty?
Available on request and confirmed in the written quotation.
When can it ship?
Confirm before quotation after quantity and destination are known.
Has it been tested?
Subject to verification. Request the applicable test scope and available records.
Which payment methods are supported?
Available on request and listed on the proforma invoice.
How is the transaction verified?
Request an itemized quotation, company and banking details, current-unit verification, invoice and shipment documentation.
|
