Product Name:3300 XL standard extension cable
Brand Name:Bently Nevada
Model Number:330130-045-00-CN
Country of Origin:USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330130-045-00-CN |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Product Type | Proximity transducer system extension cable for vibration and position monitoring |
| Model | 330130-045-00-CN extension cable, compatible with 3300 XL 8 mm system architecture |
| Cable Length | 4.5 meters extension cable for probe-to-proximitor sensor connection |
| Cable Construction | 75Ω triaxial shielded cable design for low-noise signal transmission |
| Connector Type | Gold-plated ClickLoc connectors for secure and tool-free installation |
| Protection Options | Optional armored, FluidLoc, and connector protector configurations |
| Signal Function | Transmits dynamic vibration and position signals from probe to monitoring system |
| Electrical Resistance | Low resistance design ensuring stable signal integrity over extended distances |
| Installation Type | Industrial field wiring compatible with DIN and panel-mounted proximity systems |
| Dimension | Flexible cable structure, designed for routing in confined industrial installations |
| Weight | Approximately 0.15–0.6 kg depending on armor and protection options |
| Temperature Range | Suitable for high-temperature industrial environments with extended cable variants |
| Compliance | Designed for use in ATEX, IECEx, and industrial certified monitoring systems |
The 330130-045-00-CN is a 3300 XL standard extension cable designed for use within Bently Nevada proximity transducer systems. It forms a critical part of the measurement chain by connecting the probe to the Proximitor sensor while maintaining high signal integrity for vibration and position monitoring applications.
The 330130-045-00-CN is engineered for compatibility with the 3300 XL 8 mm system, ensuring accurate transmission of both static and dynamic signals. It supports stable operation across industrial environments, including rotating machinery monitoring where precision and reliability are essential.
With options such as armored protection, FluidLoc sealing, and connector protectors, the cable is optimized for harsh operating conditions. Its robust triaxial construction and low-noise signal performance make it suitable for long-distance field wiring in critical machinery protection systems.
Power plants: Used for turbine vibration monitoring, generator shaft position tracking, and continuous condition monitoring systems.
Substations: Enables auxiliary rotating equipment signal transmission and monitoring integration.
Chemical plants: Supports safe signal wiring in process automation and intrinsically safe monitoring environments.
Steel mills: Performs reliably in high temperature, vibration, and electromagnetic interference conditions.
Machinery manufacturing plants: Applied in compressors, pumps, fans, and automated production equipment monitoring.
Q1: What is the main function of the 330130-045-00-CN cable?
A1: It connects the proximity probe to the Proximitor sensor for vibration and position signal transmission.
Q2: What system is it compatible with?
A2: It is designed for the Bently Nevada 3300 XL 8 mm proximity transducer system.
Q3: Can this cable be used in harsh environments?
A3: Yes, it supports armored and FluidLoc options for industrial and harsh conditions.
Q4: What is the standard length of this model?
A4: The 330130-045-00-CN version provides a 4.5-meter cable length.
Q5: What type of connectors are used?
A5: It uses gold-plated ClickLoc connectors for secure and reliable installation.
|
Number |
Description |
|
148722-01 |
3300 XL Test Plug with three color-coded 1-meter leads and banana plugs for testing Proximitor Sensor performance without disconnecting field wiring. |
|
04310310 |
3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor installation. |
|
03200006 |
Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors. |
|
40113-02 |
Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools. |
|
136536-01 |
Connector protector adapter for compatibility with pre-1998 installation tools used with 75Ω ClickLoc connectors. |
|
40180-02 |
Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables. |
|
03839410 |
75Ω triaxial male connector protector for extension cable connections, providing environmental protection against moisture and contaminants. |
|
03839420 |
75Ω triaxial female connector protector for probe and extension cable connections, providing environmental sealing and connector protection. |
|
04301007 |
3/8-24 probe lock nut with dual safety-wire holes for secure probe mounting in vibration-prone applications. |
|
04301008 |
M10 × 1 probe lock nut with dual safety-wire holes for secure installation and retention of proximity probes. |
|
330153-01 |
3300 XL Connector Kit containing male and female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for cable termination and maintenance. |
