Product Name:3300 XL connector kit
Brand Name:Bently Nevada
Model Number:330153-01
Country of Origin: USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330153-01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
The 330153-01 3300 XL connector kit is designed for secure termination and reliable field connection of 3300 XL 8 mm proximity probe systems. It supports stable signal transmission between probes and extension cables, ensuring consistent performance in vibration and position monitoring applications.
This kit, compatible with 330153-01 and related 3300 XL components, includes precision-engineered ClickLoc connectors, protective sleeves, and sealing accessories. These elements help improve connection integrity, reduce environmental impact, and enhance long-term operational stability in demanding industrial environments.
As part of the Bently Nevada 3300 XL platform, the connector kit ensures easy installation, strong mechanical locking, and high resistance to vibration and contamination. It is widely used in turbine, compressor, and rotating equipment monitoring systems requiring dependable sensor connectivity.
| Item | Description |
|---|---|
| Model | 330153-01 |
| Product Type | 3300 XL Connector Kit |
| Compatible System | 3300 XL 8 mm Proximity System |
| Connector Type | Gold-plated ClickLoc connectors |
| Kit Contents | Male & female connectors, sleeves, tubing, silicone tape |
| Material | FEP tubing, corrosion-resistant metal parts |
| Function | Probe-to-extension cable connection |
| Dimension (Kit Box) | Approx. 120 mm × 80 mm × 30 mm |
| Connector Size | Standard industrial ClickLoc interface |
| Weight | Approx. 0.15–0.25 kg |
| Operating Environment | Industrial vibration & high EMI areas |
| Installation Type | Tool-free finger-tight connection |
Q1: What is the purpose of 330153-01 connector kit?
A1: It provides secure and protected electrical connection for 3300 XL 8 mm probe systems.
Q2: Is 330153-01 compatible with all 3300 XL probes?
A2: Yes, it is designed for standard 3300 XL 8 mm probe and extension cable interfaces.
Q3: Does the kit require special installation tools?
A3: No, it uses ClickLoc connectors that can be installed by finger-tight method.
Q4: What components are included in the kit?
A4: It includes connector pairs, sleeves, slit tubing, and silicone sealing tape.
Q5: Where is this connector kit commonly used?
A5: It is widely used in turbines, compressors, and industrial monitoring systems.
| Number | Description |
|---|---|
| 04310310 | 3300 XL Proximitor sensor panel-mount screw (6-32 UNC thread forming type). Four screws are required per sensor; supplied with standard Proximitor housings (3300 XL panel-mount option). |
| 03200006 | Silicone self-fusing tape roll (9.1 m / 10 yards). Used for connector protection, electrical insulation, and environmental sealing. Not recommended for internal machine casing use. |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including installation tools and protective components. |
| 136536-01 | Connector protector adapter designed to allow use of pre-1998 installation tools with 75Ω ClickLoc connector systems. |
| 40180-02 | Connector protectors package containing 10 pairs for 3300 XL 8 mm probes and extension cables, providing environmental sealing protection. |
| 03839410 | 75Ω triaxial male connector protector for extension cables, designed to protect probe and sensor connections from environmental exposure. |
| 03839420 | 75Ω triaxial female connector protector for probe leads and extension cables, ensuring secure environmental protection of electrical connections. |
| 04301007 | 3/8-24 probe lock nut with safety wire holes; includes dual drilled holes for securing the nut with safety wire in high-vibration applications. |
| 04301008 | M10 x 1 probe lock nut with safety wire holes; designed with dual drilled holes for secure mechanical locking using safety wire. |
