Bently Nevada 330930-040-00-05 3300 NSv Extension Cable In stock

Bently Nevada 330930-040-00-05 3300 NSv Extension Cable In stock

Product Name:3300 NSv Extension Cable

Brand Name:Bently Nevada

Model Number:330930-040-00-05

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330930 040 00 05 3300 nsv extension cable in stock-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330930-040-00-05
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Description
Model	330930-040-00-05
System	3300 XL NSv Extension Cable
Cable Length	4.0 meters
Cable Type	Coaxial, 75 Ω NSv system cable
Armor	Stainless steel armored design
Jacket Material	FEP / optional FluidLoc configuration
Connector Type	Gold-plated ClickLoc connectors
Operating Temperature	-52°C to +177°C
Weight	0.08kg
Minimum Bend Radius	25.4 mm
Electrical Resistance	Low-loss signal transmission design
Dimension	18x18x2cm

Description

The 330930-040-00-05 is a high-performance extension component designed for the 3300 XL NSv Proximity Transducer System, ensuring stable signal transmission between probe and Proximitor sensor. It is engineered for compact machinery installations where vibration accuracy and mechanical reliability are critical.

Built with reinforced construction and optional stainless-steel armor, the cable provides strong resistance against mechanical stress, oil exposure, and industrial contamination. The FluidLoc and FEP jacket options further enhance environmental protection, making it suitable for harsh rotating equipment applications.

As part of Bently Nevada’s advanced monitoring ecosystem, this extension cable supports precise eddy-current measurement for vibration, position, and speed monitoring in turbines, compressors, and industrial rotating assets. It ensures long-term durability and seamless integration within existing 3300 XL NSv configurations.

Applications

Power plants: Used for generator set vibration monitoring and relay protection systems
Substations: Enables bus differential control, switchyard signal acquisition, and line protection
Chemical plants: Supports intrinsically safe monitoring and process automation integration
Steel mills: Performs reliable control in high-temperature and EMI-heavy environments
Machinery manufacturing: Used in automation lines, robotics systems, and packaging equipment control

Features

Armored stainless-steel construction for mechanical protection
FluidLoc option prevents fluid ingress in harsh environments
High-integrity ClickLoc connectors for secure signal transmission
Compatible with Bently Nevada 3300 XL NSv probe and Proximitor systems
Designed for long-distance stable vibration signal transfer

Functions

Extends probe-to-sensor connection in monitoring systems
Ensures accurate eddy-current signal transmission
Reduces noise and interference in industrial environments
Maintains stable vibration and position measurement integrity
Supports predictive maintenance and machine health monitoring

FAQ

Q1: What system is 330930-040-00-05 used with?
A1: It is designed for the Bently Nevada 3300 XL NSv proximity transducer system.

Q2: What is the cable length of this model?
A2: The standard length is 4.0 meters.

Q3: Does it support armored protection?
A3: Yes, it includes stainless steel armored configuration for harsh environments.

Q4: Can it be used in oil or fluid environments?
A4: Yes, FluidLoc and FEP jacket options provide enhanced fluid resistance.

Q5: Is it compatible with older 3300 systems?
A5: It is mainly optimized for NSv systems but supports selected backward-compatible setups.

Spares

Number	Describe
147357	3300 XL NSv Proximitor User Guide for installation, configuration, and system reference of NSv proximity transducer systems.
02120015	Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, supplied for industrial signal wiring (length specified per order).
138492-01	Replacement panel-mount mounting pad designed for secure installation of 3300 XL Proximitor sensor housing.
138493-01	Replacement DIN-mount mounting pad for DIN-rail installation of Proximitor sensor modules.
01609137	BNC (F) to banana plug adapter used for test and diagnostic connections in transducer system calibration.
01609138	Proximitor connector test pin wiring set with dual test pins to BNC (F) interface for signal verification and diagnostics.
40971-04	50 Ω BNC cable (two BNC male connectors) used with adapters for performance testing via Proximitor sensor test pin ports.
04310310	Panel-mount screw kit for 3300 XL Proximitor sensor housing, includes 6-32 UNC thread-forming mounting screw.
03200006	Silicone self-fusing tape roll (9.1 m) for environmental protection and electrical insulation of connectors in industrial conditions.
40113-03	Connector protector kit for 3300 NSv probes and extension cables, including installation tools and protective components.
136536-01	Connector protector adapter enabling compatibility between legacy installation tools and 75 Ω ClickLoc connectors.
40180-03	Connector protectors package containing 10 pairs for environmental sealing of probe and extension cable connectors.
03800000	Male connector protector for extension cable connection, providing environmental sealing and mechanical protection.
03800001	Female connector protector for probe lead and Proximitor connections, ensuring contamination and moisture resistance.
