Product Name: Motor Management Relay
Brand Name: GE
Model Number:469-P5-HI-A1
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
General Electric |
Model Number: |
469-P5-HI-A1 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Specification |
|
Type |
Microprocessor-based motor management relay |
|
Phase CT Secondary |
5 A |
|
Control Power |
|
|
Phase CT Primary Range |
|
|
Analog Outputs |
4 channels (0–1 mA) |
|
Display |
Enhanced LCD |
|
RTD Inputs |
|
|
Output Relays |
6 Form-C electromechanical relays |
|
Operating Temperature |
0 to 60°C (32 to 140°F) |
|
Storage Temperature |
-40 to 85°C (-40 to 185°F) |
|
Pollution Degree |
|
|
Insulation Voltage |
300 V |
|
Dimensions |
18.5x18x23cm |
|
Weight |
4.94kg |
The 469-P5-HI-A1 is a microprocessor-based motor management relay from GE Multilin's SR family, engineered for comprehensive protection and control of medium to large horsepower motors. This 469-P5-HI-A1 model features 5 A phase CT secondaries, a high-range control power supply (90–300 V DC / 70–265 V AC), and four 0–1 mA analog outputs. Housed in a rugged drawout case, the 469-P5-HI-A1 integrates motor protection, fault diagnostics, power metering, and RTU functions into a single cost-effective package.
Six Form-C output relays for trips, alarms, and start blocks
12 configurable RTD inputs for stator, bearing, and ambient temperature monitoring
Four 0–1 mA analog outputs for transducer signals
Enhanced LCD display for clear local interface
Drawout case design for easy maintenance and testing
Optional conformal coating for harsh environment protection
The relay provides comprehensive motor protection including overload, short circuit, ground fault, unbalance, and thermal modeling. It performs power metering (kW, kvar, kVA, power factor) and fault diagnostics with pre-trip data capture. The unit supports RTD temperature monitoring, analog input/output processing, and Modbus communication via RS232 and RS485 ports.
Q1: What type of phase CT secondaries does the 469-P5-HI-A1 support?
A1: The module supports 5 A phase CT secondaries.
Q2: What is the control power range for the 469-P5-HI-A1?
A2: It accepts 90–300 V DC or 70–265 V AC at 48–62 Hz.
Q3: How many RTD inputs does the 469-P5-HI-A1 provide?
A3: The relay offers 12 RTD inputs for stator, bearing, ambient, and other temperature monitoring.
Q4: What communication ports are available on the 469-P5-HI-A1?
A4: It features a front RS232 port and two rear RS485 ports.
Q5: What is the primary CT range for the 469-P5-HI-A1?
A5: The phase CT primary can be set from 1 to 5000 A.
